| General Specifications |
• Product Type: Stand-up spout pouch with heat-sealed closure • Application: Chocolate sauce, syrups, and viscous liquid packaging • Capacity Range: 200ml–5L (customizable) |
| Material Structure |
• Base Laminate: PET (12μm) / Adhesive / Nylon (15μm) / EVOH Barrier (6μm) / LDPE (70μm) • Barrier Properties: EVOH layer reduces oxygen transmission rate (OTR) to ≤0.05 cc/m²/day at 23°C, 0% RH
• Sealant Layer: Food-grade LDPE for hot-fill compatibility |
| Thermal Resistance |
• Hot-Fill Tolerance: 120°C for ≤30 seconds without deformation/delamination • Post-Fill Stability: Maintains seal integrity during rapid cooling (100°C → 25°C in ≤5 mins) • Operational Range: -40°C to 130°C (short-term exposure) |
| Barrier Performance |
• Oxygen Barrier: EVOH layer blocks ≥99.9% O₂ ingress
• Moisture Barrier: Water vapor transmission rate (WVTR) ≤0.5 g/m²/day at 38°C, 90% RH • Light Barrier: Optional aluminum foil (9μm) for UV protection (add-on) |
| Safety & Compliance |
• Certifications: FDA 21 CFR 177.1390 + EC1935/2004 (food contact materials) • Migration Limits: Heavy metals ≤0.1 ppm; non-volatile residues ≤50 mg/kg
• Chemical Resistance: Resists oil/fat penetration from cocoa butter |
| Functional Features |
• Spout Design: Leak-proof screw cap (PP material) with tamper-evident ring • Seal Strength: ≥3.5 N/15mm (ASTM F88 seal integrity test) • Shelf Life: 12–18 months (barrier-dependent) |
| Customization Options |
• Printing: Rotogravure with up to 10 colors; water-based inks (REACH/ROHS compliant) • Add-ons: Resealable zippers, tear notches, matte/gloss lamination |
