Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
Specifications
Brand Name :
Bright Pack
Model Number :
B010
Certification :
patent for invention、BRC、GRS
Place of Origin :
Guangdong,China
MOQ :
100pcs
Price :
$3-3.5/kg
Payment Terms :
T/T,Western Union
Supply Ability :
200000pcs/day
Delivery Time :
11-13work days
Packaging Details :
Export special carton packaging and plate
Customization :
Support
Colour :
Up To 10 Colour Or No Printed
Odor Proof :
Yes
Custom Order :
YES.
Colors :
CMYK/Pantone
Sample :
Free
Puncture Resistant :
Yes
Packaging Type :
Bulk Pack
Quantity Per Pack :
100
Recyclable :
Yes
Quantity :
Pack of 100 bags
Bag Type :
Three side seal stand up bag
Bpa Free :
Yes
Color :
Transparent
Height :
115 MM
Description


​Product Attributes Table​

Attribute Description Reference
​Material Structure​ Multi-layer composite (typically 3–7 layers): PET/PP outer + SiOx/AlOx barrier + PE/PP sealant layer
5
8
​Transparency​ >90% visible light transmittance (VLT); <2% haze
3
6
​Barrier Performance​ - ​Oxygen Transmission Rate (OTR)​: ≤0.05 cm³/m²/day (ASTM F1249)
- ​Water Vapor Transmission Rate (WVTR)​: ≤0.1 g/m²/day (ASTM D3985)
1
5
​Functional Coating​ Optional: UV-blocking (>90% UV-A/UV-B), anti-fog (contact angle >90°), or anti-static (surface resistivity ≤109 Ω/sq)
3
7
​Sealability​ Heat-sealable inner layer (PE/PP); seal strength: 5–15 N/15mm; temperature range: 120°C–180°C
7
8
​Flexibility & Durability Puncture resistance: ≥30 N; elongation at break: 150–300%
5
9
​Applications​ Food packaging (fresh produce, snacks), flexible electronics (OLED displays), medical device barrier films
6
7

​Product Specifications Table​

Parameter Specification Reference
​Thickness​ 12–250 μm (standard: 25 μm, 50 μm, 100 μm)
5
8
​Width​ 150–1650 mm (customizable for VFFS/HFFS machines)
5
​Roll Dimensions​ - Core ID: 76 mm (3") or 152 mm (6")
- Length: 1000–5000 meters
5
7
​Optical Properties​ - VLT: ≥90% @550 nm
- Haze: ≤2%
- Gloss: >95 GU (60°)
3
6
​Barrier Metrics​ - OTR: ≤0.05 cm³/m²/day @23°C, 0% RH
- WVTR: ≤0.1 g/m²/day @38°C, 90% RH
1
​Mechanical Strength​ - Tensile strength: MD ≥50 MPa, TD ≥45 MPa
- Tear resistance: ≥50 N/mm
5
9
​Certifications​ FDA 21 CFR, EU 10/2011, ISO 22000, RoHS, REACH
7
​Add-On Options​ - Custom printing (flexo/gravure, ≤10 colors)
- Micro-perforations
- Biodegradable variants (PLA-based)
6
8
​Packaging & MOQ​ - Dust-free rolls in anti-static wrapping
- MOQ: 500 kg (bulk orders); lead time: 10–20 days

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier

Multi-Layer Transparent Composite Film Roll 0.05 OTR Barrier
