Specifications
Brand Name :
LTMG
Model Number :
LT12J
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD 68536-69586 PER SET
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 unit per month
Delivery Time :
30 days
Packaging Details :
nude packing, in container
Tire type :
26.5R25
Engine :
Weichai,Cummins
Rated engine :
178KW
warranty :
1 year
Max.dumping height :
3600mm
NO.of shifts :
Forward 4 For Reverse 2
Description

log charge 12 ton front end log wheel loader with log grapple

12 ton log loader feature

1. Latest generation.Heavy duty high reliability and productivity.

2. Main components from top brand,high reliability and productivity.

3. Joystick control,easier operation.

4. Comfortable operation environment.

5. Various working devices of attachment are available,such as Quick hitch,wooden fork, pipe, pallet fork, grass fork, rock bucket, bigger bucket, snow bucket, mixing bucket etc. to meet different need.

6. High pressure and safer air assist disc brake braking system

7. According to clients request, customize higher dumping and longer arm products.

The Specification of 12 ton log loader

Model LT 12J
Operating weight 22,000kg
Engine model WD10G270E201
Rated engine power 178KW
Rated rotate speed 2200r/nin
Max.torque 920N.m
Max.dumping height 3600mm
Rated load 12,000 KG
NO.of shifts Forward 4 For Reverse 2
Driving speed
Forward/ReverseⅠ 0-6.5km/h
Forward/ReverseⅡ 0-12.3km/h
Forward/ReverseⅢ 0-24km/h
Forward/ReverseIV 0-41km/h
Grade ability ≥25°
Turning angle 35°±1°
Overall length 8600mm
Overall width 3130mm
Overall height 3550mm
Wheel base 3550mm
Track base 2510mm
Torque converter Model: YJ375X3 ratio:3.166
Cycling time 14s
Tire type 26.5R25

Forward 4 For Reverse 2 Front Loader Grapple Forestry Logging EquipmentForward 4 For Reverse 2 Front Loader Grapple Forestry Logging EquipmentForward 4 For Reverse 2 Front Loader Grapple Forestry Logging EquipmentForward 4 For Reverse 2 Front Loader Grapple Forestry Logging Equipment

    • After-sale Service
      Nowadays more than100 agents around the world can supply LTMG professional after-sale service.
      All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
      Detail clauses and policies please check our website and product certificate.
