High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
Specifications
material processed :
Chemicals, Food
Product name :
High-quality High Speed Laboratory Liquid Mixer
Working pressure :
0.1-0.8MPa
mixer type :
Agitator
Keyword :
lab scale homogenizer
additional capabilities :
Milling
key selling points :
Long Service Life
core components :
Motor, Other, Bearing, Engine, Other
Delivery Time :
7 work days
Power (kW) :
1 kW
material :
SUS304, SUS316L
dimension(l*w*h) :
300*325*780mm
Capacity :
5 L
Gas consumption :
110L / min
Price :
$4,000
product type :
Cosmetic
machinery test report :
Provided
Brand Name :
Cosmati
voltage :
can be customized
warranty :
1 Year
Packaging Details :
wooden cases
Material :
Stainless Steel 304 / SUS316L
range of spindle speed(r.p.m) :
1200 - 22000 r.p.m
Application :
Liquid with Suspended Solids
Place of Origin :
Guangdong, China
MOQ :
1
Voltage :
Custom Made
video outgoing-inspection :
Provided
Mixing capacity :
0-5l water (optional)
weight (kg) :
16
Function :
Mixing Raw Material
Supply Ability :
10000 set
Machine Type :
Dispersion Blender Mixer
Feature :
High Efficiency
Payment Terms :
TT
Description
Ultra Shear Batch Laboratory Homogenizer High Speed 22000RPM Dissolver Tabletop Emulsifier Mixer
Suitable for cosmetic, biochemical, food, nanomaterials, coatings, adhesives, daily chemicals, printing and dyeing, petrochemical, paper chemistry, polyurethane, inorganic salt, asphalt, silicone, pesticide, water treatment, heavy oil emulsification and other industries

Features

1. The mixing part adopts a quick-installation design, which can quickly replace different types of mixing parts to realize one machine with multiple functions.
2. The high-shear mixing section has a higher speed, up to 22,000 rpm. The strong shear force can obtain a more refined treatment effect and reduce the particle size.
3. The unique strong circulation axial flow technology makes the material circulation more intense during the stirring process, and the shear mixing is more sufficient and uniform, thereby greatly improving the emulsification and dispersion efficiency and effectively shortening the processing time.
4. The strong circulation of the liquid flow also makes it have a good treatment effect on high-viscosity materials.
Detailed
Model
CM-HCM-2.5
Dimensions
L300xW325xH780(mm)
Speed
900-22000rpm;
900-10000rpm
Contacted part
SS316L; SUS304; PTFE
Power supply
Customiezd 1P/220V/50Hz
Max. Capacity
5L (based on water)
Output power
0.75KW
Weight
16KG
High shear homogenizer mixer head
Material: SS316L+PTFE
High speed dispersion mixer head
Material: SS316L
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
Factory profile
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver


Engineer case
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver

High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver

Trade show participation
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver
Packaging & shipping specifications
High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver

Application

High Shear Homogenizer Lab 22000RPM Tabletop Emulsifier Mixer Dissolver

FAQ

Q1: What products can this lab homogenizer process?
A: It is suitable for cosmetic, chemical and food formulations such as creams, lotions, gels, emulsions and other liquid or semi-liquid materials.

Q2: What is the speed range?
A: The adjustable speed range is approximately 1,200–22,000 rpm, allowing flexible processing for different formulations.

Q3: What is the motor power?
A: The standard motor power is 1 kW, suitable for laboratory testing, formulation development and small-batch processing.

Q4: What material is used for the homogenizing parts?
A: SUS304 and SUS316L stainless steel options are available according to product and processing requirements.

Q5: Is this machine suitable for laboratory use?
A: Yes. Its compact tabletop design and 16 kg weight make it suitable for R&D laboratories, sample testing and small-scale production.
