Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Specifications
Packaging Details :
wooden cases
warranty :
1 Year
video outgoing-inspection :
Provided
Weight (KG) :
150
packaging type :
Case
Keywords :
shampoo semi automatic filler
Filling nozzles :
1/2/4/6/8/(customized)
Supply Ability :
10000 set
MOQ :
1
Delivery Time :
7 work days
dimension(l*w*h) :
1200*280*750mm
core components :
Pressure Vessel, Pump, Gear, Other
key selling points :
High Productivity
machinery test report :
Provided
Degree of automation :
Semi-automatic
Place of Origin :
Guangdong, China
driven type :
Pneumatic
filling material :
Milk, Water, Oil, Juice
Product name :
Semi-automatic liquid filling machine
application :
Food, Chemical
Applicable bottle height :
30-250(mm)
Brand Name :
Cosmati
filling accuracy :
99.5%
After-sales Service Provided :
Online support
automatic grade :
Semi-Automatic
Applicable bottle diameter :
10-120(mm)
Payment Terms :
TT
packaging material :
Wood
Production capacity :
1-60 (cans/minute)
Price :
$1,200-1,500
Filling volume :
5-5000(ml)
Material :
316L+304 Stainless Steel
Description
Semi automatic low viscosity liquid filling machine shampoo detergent liquid soap self-suction pneumatic filler

Introduction

This semi automatic liquid filling machine is suitable for filling products of various viscosity such as water injection and ointment, shampoo, detergent, lotion, etc.
It is applied in such industries as daily chemical industry, cosmetics, food and pesticide etc. It is a new generation product
developed on the basis of the original electric combined machines
Meanwhile, it is especially suitable for use in damp conditions or conditions with explosion-proof requirements.

Features

1. Control by adopting compressing air so it is especially suitable for use in conditions with explosion-proof requirements and has security.
2. No static , do not need to touch the ground.
3. It adopts pneumatic control and forcibly orientation, so that the filling precision is high and the precision can be controlled in 2/1000(the largest filling volume as the standard)
Power supply
0, pneumatic
Working pressure
0.8kg/cm
Filling accuracy
±0.1%
Filling range
5-60ml; 15-120ml; 30-250ml; 50-500ml; 100-1000ml; 250-2500ml; 500-5000ml
Filling capacity
30-50bpm
Filling system
Control by cylinder
Filling Nozzles
1/2/4/6/8/10/12/16, (can customized)

Factory profile
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Engineer case
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Trade show participation
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Packaging & shipping specifications
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
Application
Self suction Pneumatic Filling Machine for Low Viscosity Shampoo Detergent Liquid Soap
FAQ

Q1: What materials and liquids is this machine suitable for?

A: It is specially designed for low-to-medium viscosity liquids, including shampoo, liquid soap, detergent, lotion, water-based solutions, and non-corrosive chemical/daily chemical products.

Q2: What is the filling accuracy, and how do I adjust the volume?

A: The filling accuracy is maintained within ±0.2% (2/1000) of the maximum filling volume. Volume can be easily adjusted by tuning the stroke length of the pneumatic cylinder via an intuitive handwheel or scale sensor.

Q3: Can it be used in damp or flammable/explosion-proof environments?

A: Yes. The machine operates strictly on a full pneumatic control system using compressed air. It requires zero electrical plug-in, eliminates static and risks, requires no ground-wire setup, and complies with strict explosion-proof requirements.

Q4: How does the self-suction function work, and do I need a separate pump?

A: No additional pump is needed. The machine features built-in self-suction functionality, allowing it to draw liquid directly from an external floor-standing storage tank, drum, or mobile stainless steel vessel via flexible food/chemical-grade hoses.

Q5: Is it easy to clean and change over for different liquid products?

A: Yes. Quick-disconnect tri-clamp fittings and transparent reinforced self-suction tubing enable tool-free dismantling. You can easily flush the fluid path with clean water or alcohol between batches to prevent cross-contamination.
