Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
Specifications
Brand Name :
SOOME
Model Number :
SMDX-SP-2400
Certification :
CE
Place of Origin :
Made In China
MOQ :
1 Set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 Sets/Month
Delivery Time :
1 Month
Packaging Details :
Wapped With Film
Price :
Negotiation
Condition :
New
Automatic Grade :
Semi-Auto
Material :
Steel
Warranty :
1 Year
Precision :
1MM
Power :
6KW
Description

Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine

Main features

1. One machine has two usages, can stitch single piece, double PCS and irregular shape cartons.
2. Sizes can be fully controlled by electric, size changing time need 2~3 minutes.
3. Can stitch intensive nails, single nail, double rows nail, finish in one time.
4. Paper feeding part automatic counting, finished products convey out for packing.
5. Suitable to big cartons, stitching fast and easy.
6. Can set the nails distance randomly in computer, range is 20~120mm.
7. Adopt computer display to show the malfunction.
8. The cartons have bottom but without top cover is no problem.

Detail Information

Quality:Due to high requirements for mechanical quality, raw materials selection, processing, assembly of industrial control over the industry standard, using the new design, quality management system, comprehensive tracking to every detail, delivery to the customer in both hardware and software are a high quality equipment.
Efficiency:Patent type feeding width automatic adjustment device and printing locking device with screw.With 4.0 engineering design of industrialization, both hardware and software are charged with the author’s high efficiency tools.
Service:Based on the industry’s first use of PDM design file management system, complete technical support files, regardless of the long time can still be credible commitment to customers, continuous and efficient after-service for the customer support. 24 hours service with 12 engineers.

Main Electrics

No.PartsBrandQuantity
01Servo systemYaskawa4
02Reduction gearsTaiwan2
03PLCOmron1
04Touch screenWEINVIEW1
05Power supplyTaiwan MIWE1
06TutamenSHIHLIN1
07ContactorSHIHLIN10
08Thermal protectionSHIHLIN1
10Intermediate relaySchneider8
11Terminal stripCHINT3
12DisconnectorSHIHLIN3
13Proximity switchROKO2
14Optoelectronic switchOmron1
15Button switchSchneider10
16Stitching headGuangdong2


Semi Automatic Double Head Stitching Machine , Fast Lock Paper Stitching Machine
