Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Full Automatic Paperboard Flat Bed Die Cutting Machine High Efficiency
Specifications
Brand Name :
ZHAOLI
Model Number :
1100 Model, 1300 Model, 1600 Model
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
50,000 USD
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
10 sets/Month
Delivery Time :
30 days
Packaging Details :
plastic film
Description

Technical parameter

Item Parameters
Model MY-1300
Die cutting type Pressed flat die cutting(Lower side is movable while upper side is unmovable)
Max paper transmitting size 1320*980mm
Min paper transmitting size 400*500mm
Max die cutting size 1300*960mm
Min gripper size 8mm
Max die cutting pressure 300N/cm²
Paper processed

Cardboard 200-2000 gsm

Corrugated board ≦ 6mm
Max die cutting speed 4600 sheets/h
Max feeding pile height 1400mm(above the level)
Min feeding pile height 1250mm(above the level)
Main motor power 11 kw
Total power ～18 kw
Total weight 16.5 T
Overall size

6500*2300*2346mm

(without platform and pre-paper)
7900*4300*2346

System introduction

Feeding and Collecting Part

  • The extra feeder can do paper and corrugated board,Install the vacuum pump of BECKER.
  • At the middle of head install the monitor ,worker can easily see the back
  • Pre-paper pile design and special pneumatic bench can save much time

The non-stop sampling system can check the board accurate without stop the machine
