3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
3 Ply 5 Ply Corrugated Carton Gluing Machine 2800 X 1515mm Max Feeding Size
Specifications
Brand Name :
ZHAOLI
Model Number :
BL-2400
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
30 set per month
Delivery Time :
20 days after receive deposit
Packaging Details :
plastic film packing and loaded in 20' and 40' container, then fixed with container .
product name :
3 ply 5 ply corrugated carton glue machine
other name :
corrugated carton box folder gluer
model :
BZX-2800
max feeding size :
2800 X 1515mm
machine speed :
60 m/min
machine color :
light blue and yellow
Description

3 ply 5 ply corrugated carton glue machine

Main Structure :

BZX 2800 semi automatic gluing machine is made of main frame and two little conveyors .

Main frame : frame , elevating working table , forepart conveyor , forepart correcting unit , middle conveyor , middle pressing device , end product side conveyor and electrical control device .

Technological Parameter

Parameter specification
max size ( length + width )*2 2800mm
min size ( length + width )*2 340mm
max size ( width + height ) 1515mm
min size ( width + height ) 260mm
the height of feeding 1000mm
motor power 4.0 kw
the dimension of machine 5.5m * 2.5m * 1.5m
the weight of machine 1500 kg
working speed 60 m/min

Applicable Scope And Characteristics :

v The equipment applies to the gluing for all kinds of cardboard and corrugated paper .

v Easy to operate without experience .

v One minute quickly change the size .

v The min size of width adding height is about 260mm .

v It is the ideal equipment for the carton box manufacturers .
