Specifications
Brand Name :
Dpack
Model Number :
WJ250-2200
Certification :
IOS9001
Place of Origin :
China Hebei Dongguang
MOQ :
1 Line
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
1 Line/130 Days
Delivery Time :
According to product
Packaging Details :
Wooden case or wrapping film
Model No :
WJ250-2200 7 ply corrugated cardboard production line
Design speed :
250m/min
Working speed :
220m/min(3 ply) 180-220(5 ply) 120(7 ply)
Working width :
2200mm
Description

Main technical parameter and requirements of production line

Design speed 250m/min
Working speed 220m/min(3 ply) 180-220(5 ply) 120(7 ply)
Working width 2200mm
Flute type according to the customer request

The moisture rate of reel paper

 11%±1%
Face paper 120-200g/m2
Core Paper 90-125g/m2
Liner Paper 90-150g/m2

Corrugated paper

 90-125g/m2

Model No.:WJ250-2200 7 ply corrugated cardboard production line

1, Design speed:250m/min

2, Working speed:220m/min(3 ply) 180-220(5 ply) 120(7 ply)

3, Working width:2200mm

4,Note:The testing paper should as per below request when tested the production line

Reel–paper grade not less than B.

The moisture rate of reel paper:11%±1%

* Face paper: 120-200g/m2

* Core Paper: 90-125g/m2

* Liner Paper: 90-150g/m2

* Corrugated paper: 90-125g/m2

5, Flute type:according to the customer request can be choose as below:

Dpack corrugated WJ250-2200 7 ply corrugated cardboard production line with high speed corrugating plant

6,Voltage: 380V 50Hz three-phase four-wire system(or as per clients country standard)

7,Equipment direction:Left or right transmission will be according to customer’s request.

8,Steam consumption: about 5500kg/h

Note:Customer’s self-provided part

1,Compressor main air pipeline and glue main pipeline

2,Electrical power supply, the wires for link to operate box and circuitry pipeline

3,Water source, water feeding pipeline and barrel

4,Groundsill plane installation project for water, electricity and air

5,For testing machines material,such as paper, corn starch, caustic soda and borax

6,The engine oil, lubricate oil, hydraulic oil, grease and high temperature lubricating

grease for equipment.

7,The food, hotel for technicians of installation and test. And provide some workers to

assist in installation.

8,Seller need to arrange at least 5 engineer to installation the machines.but

Buyer need to cooperate with our engineer

9,Buyer need to prepare the boiler 6 tons
