Specifications
Brand Name :
Dpack
Model Number :
GF－T
Certification :
IOS9001
Place of Origin :
China Hebei Dongguang
MOQ :
1Set
Price :
Negotiate
Payment Terms :
L/C, T/T
Supply Ability :
8 sets/ month
Delivery Time :
According To Product
Packaging Details :
Wooden case or wrapping film
Working pressure :
0.8-1.0MPa
Environment temperature :
-5℃----＋50℃
Compressed air output :
0.9/min
Store barrel volume :
0.9m3
Description

Technical Parameter

Working pressure:0.8-1.0MPa Environment temperature:-5℃----＋50℃

Compressed air output: 0.9/min Store barrel volume:0.9m3

Working electricity: 380V 50Hz

System total power: 7.5kw intermittent work

Characteristic

* To provide compressed air for whole production line, and keep working pressure stable. *Compressed air station supply compressed air, pressure is stable and quantity is enough.

* The air will be filtered in the station, to keep air clean and stable.

* Each air-using machine will get air through main pipeline, independently control and not affecting with other.

* Each air-using machine will adjust air pressure according to actual requirement, equipped with pressure monitor dial plate.

* The pipelines with machinery will be made of copper or high quality of PVC pipe, reliable and durable.

* Before the compressed air enter into the air-using machine, second filter and oil-frog treatment will be required, so as to make sure relative parts normal and safety used.

*Combines pneumatic system and electric control system into one body, operate them together.

Raw material and bought-in parts

Air compressor: 7.5kw

Store barrel materials: 20# steel Ji Steel, thickness: 20mm pressure container is made according to pressure container safety standard.

Proportional valves, pressure adjustment valves, pressure meter, air 3 set unit, electromagnetic valves, filtering device, made in Yadeke Taiwan
