Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine
Specifications
加工塑料类型 :
PP/PVC/WPC/PE/ABS/XPS/聚苯乙烯
应用 :
颗粒
螺杆设计 :
双螺杆
双螺杆类型 :
同向平行双螺杆
螺杆材质 :
38CrMoALA
螺杆直径（mm） :
71
螺杆长径比 :
40:1
螺杆转速 (rpm) :
500 rpm
原产地 :
Jiangsu, China
品牌 :
YongJie
电压 :
380V 50HZ
尺寸(长×宽×高) :
型号
功率 （kW） :
132
保修期 :
1年
核心卖点 :
全自动
视频出厂验货 :
可提供
核心组件 :
PLC, 齿轮箱
机械测试报告 :
可提供
关键词 :
木塑复合机械
姓名 :
永洁
保修 :
1年
颜色 :
任何颜色作为您的要求
L/D :
32-64
RPM ( r/min) :
400/500/600/800
扭矩 (N.m) :
1015/1005/990/900
T/N :
4.7/4.6/4.2
容量 (Kg/h) :
225-800kg/h
认证 :
CE ISO9001
状态 :
New
展示厅地点（在海外哪些国家有样品间） :
None
适用行业 :
生产车间
核心组件质保期 :
1年
重量 :
5000 KG
Description

Competitive-price PP/bamboo powder plastic compounding machine wood plastic pellet machine

The company concentrated on research development and manufacturing “high level, accurate, highly sophisticated series product —Co-rotating parallel “cordwood” twin screw extruder. We have provided customer first-class products with strong torque, high production, energy conservation and environmental protection products.

Model Diameter(mm) L/D RPM ( r/min) Power (Kw) Torque(N.m) T/N Capacity (Kg/h)
SJSL-20 20 32-44 600 5.5 30 4.8 6.5-15
SJSL-36 36 32-48 600 15 115 4.2 30-75
SJSL-51A 51 32-52 500 45 405 5.1 100-200
SJSL-51B 51 32-52 600 55 415 5.2 150-25
SJSL-63A 63 32-62 400 55 620 4.4 160-250
500 75 675 4.8 200-300

SJSL-63B

 63 32-64 600 90 675 4.8 225-375
800 110 620 4.4 300-500
SJSL-75A 72 32-64 400 90 1015 4.7 225-350
500 110 1005 4.6 300-550
SJSL-75B 72 32-64 600 132 990 4.6 400-650
800 160 900 4.2 480-800
SJSL-92A 92 32-64 400 250 2815 5.9 650-1050
500 2250 4.7 750-1250
SJSL-92B 92 32-64 600 280 2365 5.0 900-1500
800 2250 4.7 1200-2000
SJSL-135A 135 32-48 400 315 6190 4.6 1500-2500
SJSL-135B 135 32-48 500 400 6750 5.1 200-3500
Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Application for wood plastic pellet machine

1. Masterbatch enforcing modification: PE, EVA + calcium carbonate, talc, titanium

dioxide, PVC, PP, carbon black.

2. Degradable master batch: PE, PS, etc. + starch, additives etc.

3. Anti-flame master batch: PE, EVA, etc. + Mg(OH)2, Al2(OH)3, etc.

Auxiliary

Air-cooling pelletizer cover

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

cyclone

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Blower

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Vibrating sieve

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Product bin

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Other product

Pelletizing in the water line

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Air-cooling strand pelletizing line

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Water-ring Hot-face pelletizing line

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Water-cooling stand pelletizing line

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

Competitive-price PP/bamboo Powder Plastic Compounding Machine Wood Plastic Pellet Machine

FAQ

1. Are you a factory or trading company?

Both.

2. Where is your factory located? How can I visit there?

Our factory is located in industrial centralized area of Moling town, Jiangning, Nanjing, China.

(1) You can fly to Nanjing Airport directly. We will pick you up on Nanjing Lukou International airport;

(2) You can fly to Shanghai Pudong International Airport then come to Nanjing by High-speed railway, then we will pick you up in the railway station.

3. What's your advantages?

(1) Excellent quality control

(2) First-class service

(3) Professional Tech. and R&D team

(4) Quick manufacturing time

(5) Quite competitive price

4. How long is the delivery time?

Under normal conditions, products are delivered within 35 days.

5. How can I know the stauts of my order?

We will send you photos and videos of your order at different satge in time and keep you informed of the latest information.

6. How long is the warranty?

We can offer one-year warranty for the whole machine.
