Specifications
Brand Name :
Aoxing
Model Number :
XY-2
Certification :
ISO9001
Place of Origin :
Hebei,China
MOQ :
1 Set
Packaging Details :
in New Strong Plywood Case
Model NO :
XY-2
Condition :
New
Motor :
DC Motor
Drill Hole Diameter :
76-300mm
Drill Hole Depth :
300m
Bit Type :
Diamond Bit
Drilling Way :
Rotary
Type :
Crawler
Maximum Open Hole Caliber :
260mm
End Hole Caliber :
75mm
Max Torque (Nm) :
2760
Angle Range :
0-90°
Spindle Max Pull Force(Kn) :
60
Spindle Stroke (mm) :
600
Hoist Max Life Capacity with Single Rope :
30
Spindle Inner Dia (mm) :
76
Oil Pump :
Scb32/12
Origin :
China
Description

Y2 Drilling Rig Has High Efficiency in Field Mining Exploration

1. XY-2 Drilling Rig Equipment for the general exploration and investigation of solid mineral deposit, engineering geotectonic survey and concrete structure inspection holes.
2. Diamond drill bit, alloy drill bit and steel roller drill bit and so on are available for drilling according to different geological structures.
3. When the final holes are respectively 75mm and 46mm in diameter, the rated hole depths are separately 100m and 180m. The maximum of depth may not exceed 110% of that drilled in each hole. The maximum allowable hole diameter is 150 mm.

1. XY-2 Drilling Rig Equipment with hydraulic feeding device, elevated drilling efficiency, reduced labor strength.
2. XY-2 Drilling Rig Equipment is equipped with an upper spherical jaw holding mechanism and hexagonal drive drilling rod which can be replaced without shutdown, high efficiency, safe and reliable.
3. A hole bottom pressure gauge is mounted indicating the pressure in order to control the status inside the hole.
4. XY-2 Drilling Rig Equipment designed into compact structure, small volume, lightweight, high detachability, easy transportation and suitable for the operations in plains or mountain areas.

Drilling capacity(m) 73 rod 100
60 rod 200
50 rod 380
42 rod 530
Spindle speed(r/min) Forward 65;114;180;248;
310;538;849;1172
Reverse 51;242
Max torque (Nm) 2760
Angle range 0-90°
Spindle max pull force(KN) 60
Spindle stroke (mm) 600
Hoist max life capacity with single rope (KN) 30
Spindle inner dia (mm) 76
Oil pump SCB32/12
Power unit Electric motor Y180L-4,22Kw
Diesel engine 395K2,19.85Kw
Inner dia of spindle (mm) 2150×900×1690
Drill body weight (excluding power)(kg) 950

Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
