7.0" TFT QM3G-70KFH PLC HMI Combo HMI Plc All In One

The all-in-one solution is to integrate the controller, operation interface, input/output, analog input/output, high-speed counting/pulse and communication port into a compact unit to meet the needs of customer equipment automation control.

PRODUCT DESCRIPTION of HMI PLC ALL IN ONE

Feature:
-Compatible with FX3G/FX3U/FX3S PLC,fast operation.

-Up to 30DI/30DO,16AD/8DA.

-Default 2 PLC programming ports, 1 HMl download port.

-Supports optional one or two Rs485, CAN, WIFl, network port on PLC, and supports optional Rs232,Rs485,network port (under development)on HMI.

-Supports multi-channel high speed count and pulse functions.

1.


2.


   Display	Dimension	226*163*35.6mm
   	Cutout size	217*154mm
   	Power Consumption	6-7W
   	Feature	60K-color resistive touch screen, supports portrait display
   Memory	RAM	64MB
   	ROM	NOR Flash 16MB
   	CPU	32bit CPU 408MHz
   I/O	DI/DO	Max 30DI/30DO (max 28MR)
   	DI/DO level	Input: Passive NPN, public terminal isolated
   	DO type	Relay (MR) or transistor (MT, Y0-Y3 are MOS) or mixed (MRT) (Relay output: max load 5A/ transistor output: max load 500mA)
   	Analog I/O (optional)	Max 12AI/8AO
   	AI type (optional)	Thermocouple E/E_/K/K_/S/S_/T/T_/J/J_ / PT100/ PT1000/ NTC10K/ NTC50K/ NTC100K/
   	AO type (optional)	0~10V /0~5V/ 0~20mA/ 4~20mA/ mixed/ -5~5V/ -10~10V (2AO for 1 minus voltage)
   High-speed function	High-speed counting	Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10 KHz
   	High-speed pulse	8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz. High-speed counting + high-speed pulse < 480KHz
   Connection	HMI	Type-B HMI download port (can download PLC program through the USB penetrating function), RS232
   		1 RS485 (changed from default RS232)
   	PLC	1 Mini USB, 1 RS232 (program port)
   		1 Rs485 or 2 Rs485 COM ports (one is changed from the default Rs232 port)
   		CAN (2.0A/B) port, Ethernet port, WIFI (will occupy default RS232 port)
   Software	HMI	Coolmay mView HMI Programming Software
   	PLC	Compatible with Mitsubishi GX Developer 8.86 and WORKS 2

Maintenance and service

• Your products will be 18-month warranty excluding artificial damage.
• You would receive unlimited support via video, phone or email.
• OEM/ODM is supported, MOQ is 200 sets. More modules or functions can be customized as per your requirements.
