Specifications
Brand Name :
Coolmay
Model Number :
QM3G-43FH-24M
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 peice
Price :
Negotiable
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
15000 Units Per Week
Delivery Time :
3-8 works days
Packaging Details :
carton
CPU :
32bit CPU 408MHz
Cutout size :
120*94mm
RAM :
64MB
IO :
12DI 12DO
Description

Coolmay 4.3inch HMI PLC All-in-one Temperature Controller PLC Controller
In the field of personalized applications, coolmay technology provides users with a PLC application platform to create high-performance industrial integration control solutions for users, saving time and cost for users, improving efficiency and enhancing corporate competitiveness.

PRODUCT DESCRIPTION of HMI PLC ALL IN ONE

Feature:



  2. Model QM3G-43FH
    Dimension 134*102*34mm
    Cutout size 120*94mm
    Input 24VDC
    Power Consumption 4-6W
    HMI
    Feature 60K colors resistive touch screen, supports portrait display
    Type 4.3"TFT
    Display size 97*56mm
    Resolution(pixels) 480*272
    RAM 64MB (Please inquire if requires storing historical data)
    ROM

    NOR Flash 8MB
    CPU 32bit CPU 408MHz
    COM ports Type-C HMI download port (can download PLC program through the USB penetrating function), RS232 port
    Software Coolmay TPWorks HMI Programming Software
    PLC
    I/O level

    - Input: Passive NPN, public terminal isolated

    - Transistor output: Low level NPN, COM connect to negative

    - Relay output: Normally open dry contact
    DO type and load


    - MT: 2A/point, 4A/4 point COM, 5A/12 point COM
    MR: 2A/point, 5A/12 point COM
    High-speed counting Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10KHz

    High-speed pulse

    (Only for MT models)

    8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz.

    High-speed counting + high-speed pulse < 480KHz
    COM port 1x TYPE-C, 1x RS232, 1x RS485
    Software Compatible with GX Developer8.86 and GX WORKS 2
    Detailed info. refer to: “Coolmay QM3G-FH All-in-One User Manual”, “Coolmay CX3G/FX3GC PLC Programming Manual”, “Coolmay TP HMI User Manual”



Maintenance and service

  • Your products will be 18-month warranty excluding artificial damage.
  • You would receive unlimited support via video, phone or email.
  • OEM/ODM is supported, MOQ is 200 sets. More modules or functions can be customized as per your requirements.

Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation

Certifications & Quality Standards
Coolmay products are fully compliant with CE and RoHS regulations, and are manufactured under ISO 9001-certified quality management systems.
Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation
Application Scenarios
Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation
About Coolmay
Founded in March 2006, Coolmay stands as a premier brand in industrial automation, serving over 10,000 customers across 200+ countries. Our team of 200+ global professionals, including 40+ R&D specialists, has completed 55,000+ projects and secured 60+ intellectual property rights. We deliver advanced, reliable solutions including PLC, HMI+PLC all-in-one machines, HMI, power supply, servo drives, stepper drives, VFDs, and IoT modules—engineered for precision and efficiency in smart manufacturing.
Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation
Global Partners
Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation
Industry Exhibitions
Coolmay 4.3inch HMI PLC All-in-One Controller with 64MB RAM and RS485 RS232 for Industrial Automation
Payment Methods
We accept a variety of secure payment methods on AliExpress, including Western Union, WeChat, AliPay, and PayPal (where available), as well as international bank transfers (T/T). All transactions are protected under AliExpress Buyer Protection for your peace of mind.
Warranty & After-Sales Service
  • 18-Month Manufacturer Warranty: Covers hardware defects and system malfunctions under normal use
  • Lifetime Technical Support: Remote assistance available for configuration, firmware, and integration
  • Returns & Exchanges: For damaged shipments, please contact us within 3 days with photo evidence
Contact Information
Feel free to reach out for support, documentation, or firmware files. We will respond within 24 hours.
WhatsApp: +86 199-2529-1353
WeChat: +86 199-2529-135

FAQ

1.Precautions of using PLC transistor and relay
The PLC output is a common cathode output, the theoretical value is 1A, the actual use is less than 500mA, the COM wiring is negative, please use 24V voltage, there is no voltage output when it is used as a switch. If an external relay, the relay needs an external power supply.
The relay has a contact life, the theoretical value is 30W times, and the theoretical value of the external load does not exceed 5A. Frequently, the full load current may affect the service life, and there is no voltage out.
2.Precautions of Coolmay PLC output type selection
MT: indicates the transistor output, MR: indicates the relay output, and MRT: indicates the relay transistor mixed output.
The main differences between transistor output and relay output are:
(1)The difference in current load. At present, we use a transistor with a maximum current load of 500MA, and the maximum current load of the relay is 5A (the maximum relay current of the EX2N(S)/DX2N(S) series PLC is 3A);
(2)Output power: The transistor can only be connected to the DC24V power supply , and the relay can be connected to the DC24V and AC220V power supply ;
(3)Functional characteristics: If you need to send a pulse to drive a stepper motor, you should use the transistor output or the mixed output. Also if the output switch is active, it is recommended to use a transistor output;
(4)If both the relay and the transistor are available, it is recommended to use a transistor output because the transistor has no contact life limit and the lifetime will be longer than the relay as long as the current does not exceed the limit.
