Modbus HMI Touch Screen 65536 True Colors LED 4 Wire Resistive Panel With Ethernet Port
Modbus HMI Touch Screen 65536 True Colors LED 4 Wire Resistive Panel With Ethernet Port
Modbus HMI Touch Screen 65536 True Colors LED 4 Wire Resistive Panel With Ethernet Port
Modbus HMI Touch Screen 65536 True Colors LED 4 Wire Resistive Panel With Ethernet Port
Specifications
Brand Name :
Coolmay
Model Number :
MT6037i
Certification :
CE
Place of Origin :
CHINA, GONGDONG
MOQ :
1 peice
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
15000 Units Per Week
Delivery Time :
3-8 works days
Packaging Details :
carton
Weight(kg) :
０．３
CPU :
32bit CPU 408MHz
Contrast ratio :
400:1
Backlight :
LED
Display color :
65536 true colors
Touch type :
4-wire resistive panel
Description

Modbus Hmi Touch Screen 65536 True Colors LED4-Wire Resistive Panel Ethernet Port

Human-Machine Interface (HMI) connects industrial control equipment such as programmable logic controllers (PLC), frequency converters, DC speed regulators, and meters. It is a digital device that uses the display screen to write working parameters or input operating commands through an input unit (such as a touchpad, a mouse, etc.) to realize information interaction between humans and machines. It consists of two parts: hardware and software.

PRODUCT DESCRIPTION
The main characteristics of the touch screen:

  • Provides a large number of vector libraries and supports self-built gallery.
  • High-precision,high-reliability resistive touch panel.
  • Supports various formats of static images and GIF animations.
  • Support all fonts WINDOWS provided.
  • 60,000 TFT true color display.
  • Support vertical display.
  • Support Ethernet port and audio.
  • Default Rs232/Rs485 port,support multiple protocols.
  • Support 18 languages.

Specs Dimension 88*88*25mm
Cutout size 72*72mm
Display size 73*56mm
Weight(kg) Appox. 0.3 kg
Display Display 3.5” TFT

Resolution

(pixels)

 320*240
Brightness 300cd/m2
Contrast ratio 400:1
Backlight LED
Backlight time 60,000 h
Display color 65536 true colors
Touch type 4-wire resistive panel
Storage ROM 128MB
RAM 64MB
CPU ARM9 core 400MHz
Operating system WINCE 5.0
Interface USB port USB 2.0×1 (USB port and can be connected to external USB flash drive, mouse, etc.)
Download port Yes (Mini type B male port cable for program download
Ethernet port Optional
COM port 1 RS232 and 1 RS485
Protocol Support MODBUS, free port and common PLC communication Protocol
Other Audio Optional
Calendar Yes
Input Voltage Default as DC12~24±10%V
Consumption 100mA*24V
Protection Class IP65 (front panel)
Temperature Ambient environment: 0～50℃ | Storage environment: -20～70℃
Humidity 20%～90% RH
Certification CE
Software CoolMay HMI programming software

Packaging & Shipping
  • Packaging

The products will be under testing for 1-3 days and packed with carton box .

  • Shipping

By courier, door to door

For samples, the package will be delivered by DHL/UPS/FedEx/EMS express. Usually it will take 3-7 days to your location.

Post service

If you are not hurry but need economical delivery, we can go with packet channel. The delivery time depends on your location.

Air shipping or by sea

If bulk order, the packages will be delivered by air shipping or by ship.

Modbus HMI Touch Screen 65536 True Colors LED 4 Wire Resistive Panel With Ethernet Port

Service advantages
1. Production equipment
Coolmay, which has 15 years of expertise in automation solutions for various industries, has6000 square meters of production space and 10 production lines, many imported high-end smtplacement equipment and testing equipment, and its monthly output can reach 50,000 units.
2. Certification
Coolmay has passed the ISO9001 quality management system certification and the national high-tech enterprise certification. lts products have obtained a number of utility model patent certificatesand invention patents, and have repeatedly won many awards such as "Technical lnnovationAward" and "Innovative Product Award".
In addition, all Coolmay products have passed CE & RoHS certification.
