900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan
Specifications
Brand Name :
CPMDJ
Model Number :
CPZ12-12
Certification :
CCC
Place of Origin :
Made in China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
10000000
Delivery Time :
15-35 days
Packaging Details :
Foam+Carton
Product name :
900w Galvanized Air Centrifugal Fan Blower12 Inch Centrifugal Blower Fan
Electric Current Type :
AC
Warranty :
1 year
Type :
Centrifugal Fan
Protect Feature :
Totally Enclosed
Winding :
Copper Wire
Housing :
Aluminum
Description

900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan

Features

The series explosion-proof fans have high efficiency, low noise, no overloadad, well anticorrosive, swing resistance, vibration resistance and shock resistance, stable running and safety, reliability etc.

Construction of Centrifugal Fan Blower

CPZ Series ventilators consists of housing, impeller, width of impeller, base-plate and motor. It was developed by using high technology and with low noise and compact structure. The flow rate and total pressure are ranging from 800m3/h to 4000m3/h. It is driven by single-phase motor. It is an ideal subsidiary equipment for airflow changeable air conditioners,tube type units, VAV system, heating and ventilating air-conditioners, purification equipment, and other kind of fan system.

CPZ series ventilators are equipped with single-phase 220V/50Hz three speed motors,which are flexible to change speed and easy to install. Speed can be changed by using provided silicon controlled voltage regulator and frequency converter. The voltage can be customized based on request.

Specification

Fan model Motor model Voltage Frequency Speed Air volume Current Capacitor
CPZ7-7 YDK90-6 203V-240V 50/60Hz 850RPM 1000m³/h 0.9A 5μF
YDK200-4 203V-240V 50/60Hz 1150RPM 1500m³/h 1.8A 10μF
CPZ8-8 YDK200-6 203V-240V 50/60Hz 820RPM 2000m³/h 2.0A 10μF
YDK300-4 203V-240V 50/60Hz 1200RPM 2200m³/h 2.1A 10μF
CPZ9-9 YDK250-6 203V-240V 50/60Hz 850RPM 2000m³/h 1.9A 10μF
YDK375-6 203V-240V 50/60Hz 850RPM 2000m³/h 3.5A 10μF
YDK375-4 203V-240V 50/60Hz 1200RPM 2500m³/h 3.5A 10μF
YDK550-4 203V-240V 50/60Hz 1150RPM 3250m³/h 4.6A 20μF
CPZ10-10 YDK450-6 203V-240V 50/60Hz 850RPM 3000m³/h 3.5A 20μF
YDK550-4 203V-240V 50/60Hz 1150RPM 3250m³/h 4.6A 20μF
CPZ12-9 YDK750-6 203V-240V 50/60Hz 830RPM 3000m³/h 7.2A 30μF
YDK900-4 203V-240V 50/60Hz 1250RPM 6000m³/h 8.0A 30μF
CPZ12-12 YDK750-6 203V-240V 50/60Hz 830RPM 3000m³/h 7.2A 30μF
YDK900-6 203V-240V 50/60Hz 880RPM 7000m³/h 8.6A 30μF

900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan

900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan

Certificate of HVAC Air Cooling Motor:

900w Galvanized Air Centrifugal Fan Blower 12 Inch Centrifugal Blower Fan

Our Service of HVAC Air Cooling Motor:

● Online service: we can talk on Trade manger , Email, Phone, Wechat and so on.
● Customer service: we accept OEM,with your own design, brand and label.
● Sample service:we will send samples for free, if you decide to buy our product
● Presale service: We will try our best to answer you every question in time.

● In-sale service: We will produce the goods with high quality; and pack carefully. We will also keep contact with you when the goods are ready for delivery until it reached safely.

● After-sale service:If you have any question, please contact us at any time
