25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine
Specifications
Brand Name :
CPMDJ
Model Number :
YDK95-25-6
Certification :
CCC
Place of Origin :
Made in China
MOQ :
100PCS
Price :
Negotiable
Payment Terms :
TT, LC
Supply Ability :
10000000
Delivery Time :
15-35 days
Packaging Details :
Foam+Carton
Product name :
25w Single-Phase 6poles Air Conditioner Motor For Air Cooler Machine
IP class :
IP21
Insulation :
B
bearing :
ball bearing
Housing :
Iron
Speed :
880rpm
Description

25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine

Technical Parameters for HVAC Fan Motor:

Rated Voltage 110/115/127/140V/208V/220/230V/380V/440V
Output Power 25W
Speed R. P. M 500-2600r/min
Frequency 50/60HZ
Protection Class IP21
Insulation Class BF
Type Asynchronous Air Cooler Fan Motor
Efficiency IE1, IE2, IE3, IE4
Input Power 10-1500W
Insulation Class E, B, F
Phase Single-phase
current 0.2A-2A
Poles 2/4/6/8/10
Air cooler fan motor Air Conditioning
Use Fan Motor for Air Conditioner, air cooler, cleaner,Fan Coil Unit and Other HVAC Systems
Certification CCC, CE, RoHS, UL, VDE

Application for Air Cooler Fan Motor:

YDK series motors widely usded for kinds of Air Cooler, Air Conditioner and Home appliance.

电机型号 电压(V) 频率(Hz) 功率(W) 转速(rpm) 电容(μF)
Model Voltage Frequency Output speed Capacitor
YDK95-25-6 220 50 25 880 2.5
YDK95-35-6 220 50 35 880 3
YDK95-45-6 220 50 45 880 3.5
YDK120-60-6 220 50 60 850 4
YDK139-150-6 220 50 150 900 10
YDK139-250-6 220 50 250 900 10

25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine

25w Single Phase 6 Poles Air Cooler Fan Motor , Air Conditioner Motor For Air Cooler Machine

The advantges for Air Cooler Fan Motor:

A.smooth running
B. long work times and Low temperature
C.low noise
D.steady performance
E.large loading capacity

F.High efficiency,High reliability,Little vibration,Low noise Specifications
