The control system of the trolley type annealing heating furnace is a key part to ensure its precise operation and achieve high-quality annealing effects.
Its control system usually includes the following main components and functions:
Temperature control unit: This is the core part, which uses advanced sensors to monitor the temperature inside the furnace in real time. Through intelligent temperature control algorithms such as PID control (proportional integral derivative control), the heating power is precisely adjusted to maintain the set annealing temperature curve, ensuring the accuracy and stability of the temperature, and the error can usually be controlled within a very small range.
Heating power control module: adjusts the power of the heating element according to the instructions of the temperature control unit. Segmented control can be achieved, that is, heating elements in different areas can independently adjust their power to ensure the uniformity of temperature inside the furnace.
Time control module: Set the time for each stage of the annealing process, including heating time, holding time, and cooling time, to ensure the integrity and accuracy of the process.
Operation status monitoring and alarm system: Real time monitoring of various operating parameters of the heating furnace, such as current, voltage, equipment temperature, etc. Once an abnormal situation occurs, such as high or low temperature, abnormal current and voltage, an alarm will be immediately issued and corresponding protective measures will be taken, such as stopping heating, emergency cooling, etc., to protect the safety of equipment and workpieces.
Human computer interaction interface: generally a touch screen or computer interface, where operators can easily input process parameters, view real-time temperature curves, operating status, and perform operational control.
Data recording and storage function: capable of recording all key data during the annealing process, including temperature changes, time, fault information, etc. These data are helpful for process analysis, quality traceability, and optimization improvement.
Remote control and communication interface: Some advanced control systems also have remote control functions, which can be remotely monitored and operated through the network. At the same time, communicate with other production equipment or management systems to achieve integration of automated production processes.
In summary, the control system of the trolley type annealing heating furnace provides reliable guarantees for achieving high-quality annealing treatment through precise temperature and time control, comprehensive operation monitoring, and convenient human-computer interaction.

Allocation list of the furnace body part

Specifications:

• List of main accessories (wearing parts)
