Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display
Specifications
Brand Name :
Conwin
Model Number :
Mi-P0.78
Certification :
CE；ISO；RoHS
Place of Origin :
China
MOQ :
1 sqm
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 square meters per month
Delivery Time :
15-25 working days
Packaging Details :
wooden box flight case
Usage :
Indoor
Screen dimension :
Customized Size
Tube chip color :
Full Color
Pixels pitch :
0.78125mm
Led chip :
Epistar
weight :
7kg
use :
advertising publish, retail store, shopping mall, welcome display, exhibition hall, airport, subway, Restaurant & Hotel Supplies, education
Description

Full esolution Led Display Board High Clear Small Pitch P0.78

Application:

applied for advertising publish, retail store, shopping mall, welcome display, exhibition hall, airport, subway, Restaurant & Hotel Supplies, education

Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display

Features:

16:9 golden ratio
Die-casting aluminum cabinet
3840 refresh rate and high definition display
Wireless module design
Redundancy system optional
GOB2.0 optional
Wall mounted frame optional, slim and easy installation

With ultra-high display and ultra-high resolution, images and videos can be displayed perfectly.

Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display

Seamless splicing of any size, 16:9 perfect ratio, guaranteed playback effect.

Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display

Optimal display effect through high color restoration and HDR technology.

Full Esolution LED Display Board High Clear Small Pitch P0.78 for Retail Store Display

parameter:

Pixel Pitch
Mi-P0.78
Mi-K/P0.9
Mi-K/P1.2
Mi-K/P1.5
Mi-K/P1.8
LED Type
0.78125mm
 0.9735mm 1.25mm 1.5625mm 1.875mm
Pixel Density (dots/m²)
1638400
1137778
640000
409600
285204
Module Resolution
192x216
320x180
240x135
192x108
160x90
Module Size (W*H)
150x168.75mm
300x168.75mm
300x168.75mm
300x168.75mm
300x168.75mm
Cabinet Size(mm)
600x337.5x27.5
Module QTY /Cabinet (WxH)
4x2
2x2
2x2
2x2
2x2
Weight(kg)
7kg
Maintenance Mode
Front access
Cabinet Material
Die-casting Aluminum
LED brightness correction
Yes
Brightness
≥500
Color Temperature(K)
6500K~8500K Adjustable
Grey Level
12 bit
Viewing Angle(H/V)
140*/140
Brightness/Color Uniformity
≥99.8%
Refresh Rate (Hz)
3840
Max Power Consumption(W/m²)
420
Awerage Power Consumption(W/m²)
100
IP Grade
IP31
Input Power
<Max>/
<Average>
 500/180 W/㎡
