Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Indoor P0.78 P0.9 P1.25 P1.56 P1.8 Ultra Fine HD Video Wall Display 16:9 Aluminum Cabinet LED Screen
Specifications
Brand Name :
CONWIN
Model Number :
D0.78
Certification :
CE,ROHS
Place of Origin :
China
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000sqm/month
Delivery Time :
5-8 working days
Packaging Details :
wooden box or carton
Description

What is COB LED Display?

COB (Chip on Board) is a kind of LED display packaging technology. LED light-emitting chips are directly bonded to the module board with high precision and connected to driver components on the module board through special media for overall protection of the light-emitting surface. COB packaging eliminates the two key procedures of turning LED chips into lamp beads and reflow soldering as compared to standard SMD packaging.
1- 16:9 Ratio Cabinet with 600mm×337.5mm dimension
2-150mm x 168.75mm Standard Size Module
3- The LED modules can be removed by tools on front side only 5 seconds
4- Die-casting Aluminum Cabinet Quality, but price same as iron cabinet
5-Hign refresh rate ,High contrast rate, and 256-grade automatical brightness control
6-Applications: TV studio hall, military command centers, control centers, clubs, video conference center, banquet hall, shopping mall, and star hotels etc.

Advantages of COB LED Display

Flip Chip technology:COB chips are sealed and compact. Due to the smaller size of COB chips, COB systems can achieve much higher packaging density than SMD (SMT). This novel and unique technology has many advantages over existing technologies such as SMD. It has higher resistance to external forces and a smoother, seamless surface, provides better color uniformity at close range, and has better heat dissipation, resulting in better stability and visual effects.
Superior Durability : COB has a higher level of anti-collision, moisture-proof, dust-proof, electrostatic discharge (ESD), and the surface protection level is IP54.
High Contrast Ratio: The contrast ratio of LED displays is an important parameter that determines how clear, vivid, and colorful the image is .COB can reach 15,000 to 20,000 static contrast ratio and up to 100,000 high dynamic contrast ratio.
COB P0.78 LED Screen Video Wall 16:9 Golden Ratio
The screen is gapless. 2K/4K/8K, 16:9 screen aspect ratio.
Product Description
Module
Module size
150mm x 168.75mm
Pixel pitch
0.78mm
Pixel density
1638400dots/㎡
Module resolution
192x216pixels
Contrast
15000:1
Cabinet
Cabinet size
600x337.5mm
Quantity of module
8pcs
Module power supply
5V40A
Max power
85w/cabinet
Cabinet weight
4KG/cabinet
Screen
Refresh frequency
3840Hz-7680HZ
Brightness
>=600cd
Life span
>100000hours
Grey level
≥16bits
Detailed Images
