Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania
Specifications
Brand Name :
TRUCKMAN AUTO
Model Number :
TKM240HS
Certification :
SGS, BV, CIQ
Place of Origin :
CHINA
MOQ :
1 Unit
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1500 Unit / Per Month
Delivery Time :
20 working days
Packaging Details :
Nude
Loading Tons :
40000 liter, 4x10000 liter
Tire :
12R24, radial tire
Axle :
16 tons single point axle
Support Leg :
JOST 28 tons
Material :
Carbon steel, aluminu alloy optional
Warranty :
1 year for main parts
Description

-1. 40000 Liter Fuel Tanker Trailer Details.

16 tons single point suspension axle, FUWA brand, with high loading capacity. The whole fuel tank trailer have 4 pcs comdepartment,

every comdepartment with 10,000 liter capacity and with 4 pcs separate discharge valve.

-2. 40000 Liter Fuel Tanker Trailer Main Specification.

Description Parameter value
Product Name 40000 Liter Fuel Tanker Trailer
Loading Capacity 40000 liter with 4 pcs comdepartment
Axle 2x16000kg, single point suspension
Support Leg JOST 28 tons
Tire 12R24 big tire, with one spare tire
Brake System WABCO brand and 6 pcs brake chamber
Material Q345B, high strength steel
Thickness Bottom 16mm, middle 8mm
Dimension 12000x2500x3500mm

The specification is only for reference, we could recommend the other model Fuel tanker trailer according to your request.

Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania

-3. Fuel Tanker Trailer Adopt Single Point Suspension Advantage.

Single Point Suspension Axle 40000 Liter Fuel Oil Tank Trailer For Mauritania

Single-point suspension is to reduce the common leaf spring front and rear brackets into a single bracket connected to the semi trailer. Its stress points are shared on the front and rear axles. Compared with ordinary leaf spring suspensions, single-point suspension has a higher loading capacity. Very suitable for Mauritania road request
