Temporary Duty & Event Toll Booth - Wheel-Equipped for Flexible Relocation & Rapid Deployment

Product Introduction

Advantages Introduction

• Wheel-Equipped Design for Effortless Relocation: Fitted with 4 heavy-duty rubber casters (each with a load capacity of 300kg) and brake locks, the booth can be easily moved by 2-3 people or towed by a small vehicle (e.g., pickup truck). No complex disassembly or heavy lifting equipment is required—simply unlock the brakes, push or tow to the target location, and lock the brakes for stable use. This flexibility allows it to keep pace with changing on-site needs, such as shifting construction zones or event venue adjustments.
• Rapid Deployment for Instant Use: As a pre-assembled unit, the booth arrives fully equipped with basic facilities (lighting, power sockets, toll counter). Upon reaching the site, it can be put into operation within 10-15 minutes—no on-site construction, wiring, or assembly is needed. For emergency scenarios (e.g., sudden road closures, temporary security needs), this rapid setup ensures timely deployment to avoid delays in on-site management.
• Lightweight Yet Durable Construction: The frame adopts high-strength aluminum alloy (3-4mm thick) that is 40% lighter than steel while maintaining excellent load-bearing and impact resistance. The exterior panel uses weather-resistant PVC composite material, which is waterproof, UV-resistant, and corrosion-proof—able to withstand rain, strong sunlight, and dust in outdoor temporary environments. The overall structure is designed to be robust enough for long-term temporary use (6-12 months) without performance degradation.
• Scenario-Tailored Functionality: The interior is optimized for temporary duty and toll collection needs. It features a spacious countertop (depth 60cm) for placing toll machines, card readers, or registration books; a built-in small storage cabinet for storing receipts, gloves, and other supplies; and a 180° transparent acrylic window for clear visibility and easy communication. Optional add-ons include a solar power system (for areas without mains power), a foldable awning (for shade/rain protection), and a hook for security equipment.
• Cost-Effective for Temporary Demands: Compared to building fixed booths or renting traditional facilities, this mobile booth significantly reduces costs. It avoids construction and demolition expenses, and its reusability means it can be transferred across multiple projects or events. For short-term projects (1-3 months), it is a far more economical choice than permanent solutions.

Specifications Table

Q&A

1. Q: Our construction site has uneven terrain. Can the booth be moved smoothly and stay stable on rough ground?A: Yes. The booth is equipped with large-diameter (20cm) heavy-duty rubber casters with deep treads, which provide excellent traction on uneven ground such as gravel or construction site mud. After moving to the target location, the brake locks on each caster can be firmly locked to prevent sliding. For extremely rough areas, we also provide optional adjustable support feet that can be extended to contact the ground, further enhancing stability.
2. Q: We host monthly outdoor concerts and need to move the booth between different venues. Is it easy to transport in a truck?A: Absolutely. The standard model (2.0m×1.5m×2.5m) can fit into most pickup trucks or small vans. Its lightweight design (350-450kg) means it can be loaded/unloaded with a simple hydraulic lift or even manually by 4 people. We also provide a detachable tow bar for easy towing between nearby venues (within 5km). For frequent transportation, this booth is designed to be compact and lightweight to save logistics costs.
3. Q: Some of our temporary sites have no access to mains power. Can the booth still operate normally?A: Yes. We offer a solar power upgrade option: a 100W monocrystalline solar panel paired with a 12V/100Ah lithium battery. This system can power the booth’s LED lighting, power sockets (for small devices like toll machines), and even a small fan for 8-10 hours per day. It also supports charging via mains power when available, ensuring uninterrupted operation in off-grid or remote temporary sites.
