2000Kg Lifting Rack & Pinion Hoist For Building Construction
2000Kg Lifting Rack & Pinion Hoist For Building Construction
Specifications
Brand Name :
KANGBO
Model Number :
SC200/200(BZ)
Certification :
TUV
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiate
Payment Terms :
T/T, L/C
Supply Ability :
150 sets per month
Delivery Time :
30 days
Packaging Details :
export package
Item :
Hoist For Building Construction
Application :
Construction site, building site
Purpose :
Vertical transportation of man and materials in construction site or building
Material :
Q345B cool roll steel plate
Load :
2000Kg
Feature :
Strong Applicability
Description

Strong Applicability 2000Kg Hoist For Building Construction

Hoist For Building Construction Introduction

The SC series of construction elevators are widely used at the sites of industrial and civil construction, bridge construction, underground construction, large chimney construction, ship industry and so on. Being suitable for the vertical transport of materials and people, they can also be used as permanent / semi-permanent electric elevators and in various sites like warehouses and high towers.

This series of construction elevators, which are known for their stable performance, reliable safety, easy transportation and strong adaptability, can enhance work efficiency and reduce workers labor intensity.

Hoist For Building Construction Standard Configuration


There is a small crane for conenient assembly of the construction lift.
Available in single or twin hoist cage configuration.
Frequency control makes the construction hoists starting and stopping very smoothly, with low starting current and much less wear and tear.
Manual or Automatic Controls of the hoist is optional.

Hoist For Building Construction Optional Configuration


* Rack and pinion elevator cage flap door as loading/unloading ramp.
* Elevator car 'C' door for convenient loading/unloading.
* Sliding Contact Line (Integrated Conductive Rail or Busbar) specially for rack and pinion lifts.

Hoist For Building Construction Parameters

Technical Data KP-B07, B08
Payload Capacity 2,000 kg
Lifting Speed 0–46 m/min.
Max. Lifting Height 450 m
Cage Width (internal) 1.5 m
Cage Length (internal) 3.2 m
Cage Height (internal) 2.35 m
Motor Control FC control
Engine Power 2x15 kw
Gearbox Helical Reducer
Safety Device Centrifugal Brake
Power Supply Range 380–500 V, 50 or 60 Hz, 3 phase
Mast Section Square column 650*650*1508 mm with bolted rack
Rack Module 8
