40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
Specifications
Place of Origin :
Henan, China
Condition :
New
Machine Type :
Roller-Bending Machine
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2022
Warranty of core components :
1 Year
Core Components :
PLC, Engine, Gearbox, Motor, Gear
Brand Name :
Tatooine
Raw Material :
Steel Bar
Material / Metal Processed :
Carbon steel
Power :
CNC
Automation :
Semi-automatic
Year :
2022
Weight (KG) :
280
Key Selling Points :
High-accuracy
Warranty :
1 Year
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining
Showroom Location :
None
Product Name :
Rebar Bending Machine
Model :
GW32/GW40/GW45/GW50
Control system :
CNC Control
Brand :
Tatooine
Motor Power :
4kw
Motor Speed :
1440 r/min
Bending Rebar Diameter :
6-45 mm
Spindle Speed :
9-13 r/min
Weight :
380kg
Voltage :
380V/220V
Price :
$680.00/sets 1-9 sets
MOQ :
1 set
Description
Product Description
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
Use of steel bar bending machine: It is suitable for processing various common carbon steel and rebar into various geometric shapes required for construction projects. GW50 steel bar bending machine, due to its simple structure, reliable work and sensitive operation, can bend 6-40mm or 6-50mm steel bars into various shapes required in bridges and construction projects, so it is deeply welcomed by construction, bridge prefabrication plants and construction site operators.
Tatooine rebar bending machine automatic 40mm rebar bender rebar bending machine
Specification
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
Metric dimensions specifications
Model
CNC GW 45
CNC GW 50
CNC GW 55
Host length
85 cm
100 cm
100 cm
Host width
80 cm
74 cm
98 cm
Host height
56 cm
84 cm
90 cm
Total weight
320 kg
380 kg
470 kg
Motor power
3 kw
4 kw
4 kw
Motor speed
1440 r/min
1440 r/min
1440 r/min
Motor voltage
380 v/220 v/230 v/415 v/440 v single phase or three phase
Gearbox configuration
Forged gear
Bending round steel diameter
6-32 mm
6-42 mm
6-45 mm
Bending rebar diameter
6-28 mm
6-38 mm
6-42 mm
Spindle speed
9-13 r/min
Imperial dimensions specifications
Model
CNC GW 45
CNC GW 50
CNC GW 55
Host length
33.5''
39.4''
39.4''
Host width
31.5''
29.1''
38.6''
Host height
22.1''
33.1''
35.4''
Total weight
705 ib
838 ib
1036 ib
Motor power
4 hp
5.5 hp
5.5 hp
Motor speed
1440 r/min
Motor voltage
380 v/220 v/230 v/415 v/440 v single phase or three phase
Gearbox configuration
Forged gear
Bending round steel diameter
0.24''-1.26''
0.24''-1.65''
0.24''-1.77''
Bending rebar diameter
0.24''-1.10''
0.24''-1.50''
0.24''-1.65''
Spindle speed
9-13 r/min
Product Details
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min

Product advantage

1.Copper core motor, high speed and strong power.
2.High temperature quenching forging gear, strong and durable.
3.High precision disc strip, any combination, angle.
4. Manual and numerical control models can be selected to bring you a better use experience.
5. Bendable steel products: round steel, rebar, flat steel and square steel.
6. Scope of application: construction site, steel bar processing center, bridge construction, building materials company and engineering construction.
Tatooine rebar bending machine automatic 40mm rebar bender rebar bending machine
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
Packing & Delivery
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
We adopt wooden and iron box to pack machines, better guarantee the safety and quality of products.And we adopt multiple port, multiple exit point. Such as Shanghai, Qingdao, Guangdong and other regions. Product transportation will be faster and more convenient
Certifications
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min
40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/min40mm Automatic Rebar Bending Machine with accuracy and Motor Speed of 1440 r/minTatooine rebar bending machine automatic 40mm rebar bender rebar bending machine
