Specifications
Showroom Location :
China
Rated Loading Capacity :
150 Ton
Max. Lifting Height :
60M, 65m
Max. Lifting Load :
50 ton
Place of Origin :
Hunan, China
Hydraulic Cylinder Brand :
Other
Hydraulic Pump Brand :
Kawasaki
Hydraulic Valve Brand :
Eaton
Engine Brand :
WEICHAI
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Core Components :
Pressure vessel, Bearing, Pump, Gearbox, Engine
Weight (KG) :
50000 kg
Year :
2021
Working hours :
900H
Capacity :
150 Ton
Model :
SCC1500A-6
Crane type :
Crawler crane
Engine :
Weichai engine
Max lifting capacity :
150 ton
Warranty :
6 month
Applicable Industries :
Construction Engineering
Loading capacity :
150 ton
Price :
$102,900.00/units 1-2 units
Description
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
Products Description
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine
Specification
Item
Unit
Value
Remarks
Max. lifting capacity × radius
t × m
80×4
Max. lifting capacity on fixed jib
t
7
Max. lifting capacity of luffing jib
t
15
Main boom length
m
13 - 58
Fixed jib length
m
6/18
Max. length of main boom with fixed jib
t
49+18
Luffing jib length
m
16m-34m
Max. main boom +max. luffing jib
m
43.5m+34m
Derricking angle
.
30 - 80
Fixed jib angle
.
10, 30
Max. rope speed
Hoisting winch 1
m/min
125/110
With optional free-fall function
of winches
Hoisting winch 2
125
Derricking winch
93
Slewing speed
rpm
0-2
Traveling speed
km/h
0-1.57
Max. gradeability
%
30
With basic boom and counterweight over front
Ground pressure
Mpa
0.083
Deadweight
t
72.8
With basic boom
Crane counterweight
t
27
Overall dimensions(L × W × H)
m
13500×5000 (3400) ×3200
With A-frame and main boom pivot section
Engine
Model
WP10.270N
Weichai Power
Rated power / rotational speed
kW/r/min
199/1900
Max. output torque /rotational speed
Nm/r/min
1270/1200-1500
Exhaust emission
National StageⅡ
Distance between track center × crawler contact length × crawler width
mm
2600 ×5440×800
Crawler carrier retracted
4200 ×5440×800
Crawler carrier extended
Noise
Noise level outside operator’s cab during operation
(dB)
≤107
Noise level in operator’s cab during operation
≤79
