LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
Specifications
Brand Name :
Cablein
Certification :
CE, ROHS, TUV , ETL
Place of Origin :
Shenzhen China
MOQ :
100PCS
Price :
The price ranges from $1 to $4 USD per pieces
Delivery Time :
5-8 Working Days
Packaging Details :
High Quality export carton
Payment Terms :
,T/T,Western Union
Name :
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type
Pin Configuration :
5-pin (supports 18-22 AWG wires)
Rating :
10A current, 250V AC/DC
Compliance :
Meets international electrical safety standards
Flame Resistanc :
UL94 V-0
Waterproof :
IP68/IP67
Description
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type
Specifications
  • Pin: 5 Pin
  • Current Rating(A): 10A Max
  • Material: Metal+plastic
  • Conenction Way: Push-button snap fastener
  • Operating Voltage: 500V Max
  • Assembly Wire: IP-Rated Locking Gland
  • Mounting Type: Flange Mounting Type
  • Out Door UV Resistance: Pass
  • Cable Jacket OD: 1-1.5 mm²
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type datasheet
Pins Number 2Pins 3Pins 4Pins 5Pins 7Pins 9Pins 12Pins
Rated Voltage 500V
250V
Rated Current 20A 10A 5A
Insulation voltage 2.5KV 1.5KV
IP CODE IP68
Cable Jacket OD Standard Power:⌀8-12mm Standard Signal :⌀5-6.5mm Other:⌀5-9mm
Assembly cable diameter 2.4-4mm²/14-12AWG 1-1.5mm²/18-16AWG 0.34-0.75mm²/22-20AWG
Ambient temperature -40℃~+80℃
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type Advantages:
  1. Material & Performance:
    The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments.
  2. Secure Locking Mechanism:
    Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal.
  3. Waterproof Design:
    Standard IP67 rating (IP68 optional) provides precise waterproof protection.
  4. Certifications & Compliance:
    Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.
  5. High Current Capacity: Supports 20A power transmission, making it suitable for medium-to-high-power applications
  6. Versatile Compatibility: The 4-core design allows for multiple signal/power transmissions in a single compact connector.
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type Application industries
  • Automation Equipment
  • LED Lighting
  • Security Equipment
  • Telecommunication Equipment
  • New Energy
  • Electronic Devies
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type Drawing
LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount LP20 5-Pin Waterproof Connector 10A IP67 Flange Mount
FAQ
Q: Can I customize the pin configuration (e.g., 3-pin instead of 5-pin)?
A:The LP20 series may offer different pin configurations--contact the supplier for customizable options.
Q: What is the maximum current and voltage rating?
A:This connector supports 10A current and is typically rated for 250V AC/DC, making it suitable for industrial and marine applications.
