L com LCCN3099 12G SDI connector designed for 4K Ultra HD video transmission meeting SMPTE ST 2082 1
L com LCCN3099 12G SDI connector designed for 4K Ultra HD video transmission meeting SMPTE ST 2082 1
Specifications
Description :
Coaxial Connector (RF) Assemblies RoHS
Mfr. Part # :
LCCN3099
Model Number :
LCCN3099
Description

Product Overview

L-COMs 12G-SDI 1.0/2.3 connector LCCN3099 is designed for high-resolution uncompressed video signal transmission, offering 4K and Ultra-HD quality signals that meet SMPTE ST 2082-1. These 75 Ohm connectors are cost-effective, designed for high-density applications, and backwards compatible with 2081-1. They support 12Gb/s transmission and are suitable for various video and broadband applications.

Product Attributes

  • Brand: L-com
  • Model: LCCN3099
  • Certifications: Meets SMPTE ST 2082-1 (Refer to product page for current documents)

Technical Specifications

SpecificationDetails
Connector Type1.0/2.3 Male
Impedance75 Ohms
Body GeometryStraight
Attachment TypeCrimp/Solder
Cable CompatibilityBelden 4855R, Belden 1855A
Frequency RangeDC to 12 GHz
Dimensions (Length)1.071in [27.2mm]
Dimensions (Width/Dia.)0.325in [8.26mm]
Dimensions (Height)0.325in [8.26mm]
Weight0.05lbs [22.68g]
Contact MaterialBrass
Contact PlatingGold 10 in
Insulation MaterialPTFE
Outer Conductor MaterialBrass
Outer Conductor PlatingGold 3 in
Body MaterialBrass
Body PlatingNickel 100 in minimum
Crimp Sleeve MaterialBrass
Crimp Sleeve PlatingNickel
Environmental ComplianceRefer to product page for current documents

2310201740_L-com-LCCN3099_C6444483.pdf
