L com LCCN3108 12G SDI HD BNC connector suitable for in high speed 12 Gb per second video data links
L com LCCN3108 12G SDI HD BNC connector suitable for in high speed 12 Gb per second video data links
Specifications
Description :
Coaxial Connector (RF) Assemblies RoHS
Mfr. Part # :
LCCN3108
Model Number :
LCCN3108
Description

Product Overview

L-COM's 12G-SDI HD-BNC connector LCCN3108 enables high-resolution uncompressed video signal transmission with 12Gb/s data transfer rates. These 75 Ohm connectors meet SMPTE ST 2082-1 standards, offering 4K and Ultra-HD quality. They provide 4x panel density of standard BNC connectors and are 20% lighter. Available in PCB edge-mount, straight, or right angle configurations, and as coaxial connectors for cable assemblies.

Product Attributes

  • Brand: L-com
  • Model: LCCN3108
  • Certifications: SMPTE ST 2082-1
  • Origin: USA (implied by contact information)

Technical Specifications

DescriptionSpecificationUnits
Electrical SpecificationsFrequency RangeDC to 12 GHz
Mechanical SpecificationsLength0.799in [20.29mm]
Width/Dia.0.295in [7.49mm]
Height0.409in [10.39mm]
Weight0.05lbs [22.68g]
Material SpecificationsContact MaterialBrass
Contact PlatingGold (10 in minimum)
Insulation MaterialPTFE
Outer Conductor MaterialBrass
Outer Conductor PlatingNickel (100 in minimum)
Body MaterialBrass
Body PlatingNickel (100 in minimum)

2310201740_L-com-LCCN3108_C6444488.pdf
