Specifications
Description :
Backshells and Cable Clamps RoHS
Mfr. Part # :
M28840/524SB
Model Number :
M28840/524SB
Description

Amphenol PCD M28840 Circular Connectors

Product Overview

Amphenol PCD offers a complete line of M28840 circular connectors, precision-machined to MIL-DTL-28840 specifications. These highly reliable connectors are designed for demanding shipboard applications, meeting superior mechanical shock performance and withstanding extreme environmental conditions. They are suitable for US Navy shipboard, surface craft, submarines, mission-critical combat and communications systems, mobile tactical shelters, and outdoor deployment in harsh environments. Amphenol also provides a full range of compatible backshells for strain relief, EMI, and environmental sealing.

Product Attributes

  • Brand: Amphenol PCD
  • Standard: MIL-DTL-28840
  • Applications: US Navy shipboard, surface craft, submarines, mission critical combat and communications systems, mobile tactical shelters, electronic battlefield networks, mobile emergency telecommunications (MET) stations, deployable outdoors in harsh environments.
  • Material Options: Aluminum Alloy, Stainless Steel, Copper Alloy, Beryllium Copper, Blended Elastomer
  • Plating Options: Cadmium, Zinc Nickel, Tin Zinc (Commercial only)
  • Contact Size: 20
  • Wire Accommodation: AWG 20 to AWG 28
  • Termination: Crimp, rear insert, front release
  • Keying Options: 6 options (1, 2, 3, 4, 5, 6)

Technical Specifications

Specification Details
Shell Sizes 11, 13, 15, 17, 19, 23, 25, 29, 33
Pin Counts 7, 12, 21, 31, 42, 64, 92, 121, 155
Current Rating (Size #20 contact) 7.5A (20AWG), 5.0A (22AWG), 1.5A (28AWG), 1.0A (30AWG)
Test Voltage 1000 VAC RMS at sea level
Insulation Resistance 5000 megohms min. (at ambient temp)
Contact Resistance Per SAE-AS39029
Operating Temperature -55C to +200C
Shock In accordance with MIL-S-901 grade A
Vibration In accordance with EIA-364-28
Magnetic Permeability Less than 2.0 (Aluminum)
Contact Materials Copper Alloy, 50 microinches Gold plated over nickel underplate
Socket Contact Hood Material Stainless Steel, passivated
Insulator Material High Grade Engineering Plastic
Contact Retention Clip Material Beryllium Copper
Grommet Seal Material Blended Elastomer
Contact Specifications
  • F Pin: M39029/83-508, Size 20, AWG 20-24
  • G Socket: M39029/84-509, Size 20, AWG 20-24
  • P Pin: M39029/83-450, Size 20, AWG 22-26
  • S Socket: M39029/84-452, Size 20, AWG 22-26
  • D Pin: M39029/83-451, Size 20, AWG 28-32
  • E Socket: M39029/84-453, Size 20, AWG 28-32
Backshell Types Straight, 90, 45, EMI/RFI Environmental, Metal Core Conduit, Dummy Storage Receptacle
