Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Twinaxial and triaxial Bel Fuse LPH-50 connectors ideal for testing environments requiring durable connections
Specifications
Description :
Coaxial Connector (RF) Accessories RoHS
Mfr. Part # :
LPH-50
Model Number :
LPH-50
Description

Product Overview

Cinch Connectivity Solutions, through its Trompeter brand, offers a comprehensive range of twinaxial and triaxial connectors designed for high-performance applications in military, space, and testing environments. These connectors are engineered to meet stringent military specifications, including MIL-STD-1553B data bus requirements, and are known for their reliability, durability, and precise electrical performance. The product line includes various series such as 70/370 Series (TRB/TRT), 150/3150 Series (TRS/TTM), 450 Series, and 80/380 Series (TRC/TRN), catering to diverse needs from miniature to standard sizes with features like bayonet, threaded, and push-on coupling mechanisms. They are suitable for applications requiring noise-free guarded circuits, digital data buses, and video pairs.

Product Attributes

  • Brand: Trompeter (a Cinch Connectivity Solutions brand)
  • Certifications: QPL to MIL-C-49142 (Category G and Category A)
  • Materials: Brass bodies with nickel plating, beryllium-copper contacts (gold plated), PTFE dielectrics. Hermetically sealed versions available.
  • Plating: Nickel (standard), Silver (QPL versions)

Technical Specifications

Series Type Coupling Nominal Impedance Frequency Range Voltage Rating (max. @ sea level) Insulation Resistance Durability Temperature Range
70/370 Series TRB/TRT Bayonet, Threaded, Push-on Non-constant 0-500 MHz 400 VRMS 5000 M 500 cycles minimum -65 to +165C
150/3150 Series TRS/TTM Bayonet, Threaded, Push-on Non-constant 0-500 MHz 400 VRMS 5000 M 500 cycles minimum -65 to +200C
450 Series Concentric Twinax 3-lug, 4-lug, Threaded Non-constant 0-2 MHz 900 VRMS 5000 M 500 cycles minimum -65 to 125C
80/380 Series TRC/TRN Threaded Non-constant 0-500 MHz 500 VRMS 500 M 500 cycles minimum -65 to +165C
30/330 Series TWBNC/TWTNC Two-pin Polarized Non-constant 0-500 MHz 400 VRMS 5000 M 500 cycles minimum -65 to +165C

Note: Specifications are minimum unless otherwise stated. Trompeter connectors are designed to exceed all minimum specifications.


2411220410_Bel-Fuse-LPH-50_C17671929.pdf
