Specifications
Description :
D-Sub, D-Shaped Connector Accessories RoHS
Mfr. Part # :
XM2T-0901
Model Number :
XM2T-0901
Description

D-sub Connectors XM3/XM2S

The D-sub Connectors XM3/XM2S are ideal for office automation interfacing. They offer superior noise protection and space-saving designs. The XM3B-F features multi-hole, ferrite-core connectors for enhanced high-frequency noise protection. The XM2S series provides a rugged, compact, metallized plastic hood for excellent noise protection.

Product Attributes

  • Shielded against EMI.
  • Multi-hole, ferrite-core Connectors (XM3B-F) for space-saving and superior noise protection at high frequency.
  • Rugged, compact, metallized plastic hood (XM2S) for excellent noise protection.
  • Conforms to UL standards (No. E103202).
  • Available with many kinds of standard Anchors and grounding fixtures.
  • RoHS Compliant.

Technical Specifications

ModelTypeHousing MaterialContact MaterialShell MaterialRated CurrentRated VoltageContact ResistanceInsulation ResistanceDielectric StrengthInsertion DurabilityAmbient Operating Temperature
XM3B, XM3B-F, XM3C (except 37 terminal), XM3D, XM3FSockets/Plugs with Right-angle DIP Terminals/Solder Cup TerminalsFiber-glass reinforced PBT resin (UL94V-0)Phosphor Bronze / Nickel base, gold plated (0.4 m) (Mating End) / Phosphor Bronze / Nickel base, tin plated (2-3 m) (Terminals)Steel, Nickel plated5 A300 VAC15 m max.1,000 M min.1,000 VAC for 1 min.200 times55C to 105C
XM3C (37 terminal models)Sockets/Plugs with Right-angle DIP TerminalsFiber-glass reinforced PBT resin (UL94V-0)Bronze / Nickel base, gold plated (0.4 m) (Mating End) / Bronze / Nickel base, tin plated (3 m) (Terminals)Steel, Nickel plated3 A300 VAC15 m max.1,000 M min.1,000 VAC for 1 min.200 times55C to 105C
XM2S, XM2S-E (Hoods)Straight/Right Angle Cable Connection (Metallized Plastic)ABS resin / nickel platedN/AN/A------25C to 85C
