VGA Connector 15 Positions Right Angle Through Hole Mount Foxconn DZ11AA1-H5A7-4F 2A Current Rating
VGA Connector 15 Positions Right Angle Through Hole Mount Foxconn DZ11AA1-H5A7-4F 2A Current Rating
Specifications
Number of Pins :
15P
Gender :
母
Connector Type :
高密度D-Sub
Mounting Type :
弯插
Number of Rows :
3
Color :
蓝色
Current Rating-Signal :
2A
Description :
Connector High Density D-Sub, Female 15 Position 3 Row Through Hole, Right Angle
Mfr. Part # :
DZ11AA1-H5A7-4F
Package :
Through Hole,Right Angle
Model Number :
DZ11AA1-H5A7-4F
Description

Product Overview

The Foxconn DZ Series VGA Connector is a right-angle, through-hole mount connector designed for PCB applications. It features a 2.29mm [.090"] pitch and 15 positions, offering reliable mechanical and electrical performance for various industrial and electronic systems. This connector is rated for 2A current and a dielectric withstanding voltage of 1000V AC/1min.

Product Attributes

  • Brand: Foxconn
  • Series: DZ Series
  • Type: VGA Connector
  • Mounting: Right Angle PCB Mount, Through-Hole (T/H)
  • Housing Material: Thermoplastic, UL 94V-0 rated
  • Housing Color: Blue 661C
  • Contact Material: Copper alloy
  • Lead Free: Yes

Technical Specifications

Specification Details
Pitch 2.29mm [.090"]
Number of Positions 15 Pos.
Mechanical Contact Engagement Force 0.34kg (0.75Lb) max.
Mechanical Contact Separation Force 0.021kg (0.05Lb) min.
Durability 500 Cycles
Current Rating 2A
Contact Resistance 35m max.
Dielectric Withstanding Voltage 1000V AC/1min min.
Insulation Resistance 5000M min.
Operating Temperature -20 to +85
Recommended PCB Thickness 1.35[.053]
Contact Area Plating Gold Flash (refer to ORDERING INFORMATION for details)

Ordering Information

Product Number Structure: DZ 1 1 A A 1 - H5A7 - 4F

  • Body Type: A=5.0
  • Number of Positions: 15 Pos.
  • Termination Type: Right Angle PCB Mount
  • VGA Series: DZ Series
  • Body Length: 1
  • Contact Area Plating: 1=Female
  • Lead Free Part Number: 1=Gold Flash
  • Extension Code: H5A7 - 4F

All specifications & dimensions are subject to change. Please contact your nearest Foxconn sales representative for update information.
