Durable JST RARSFP-3V-00 RA connector designed for 1.27 mm pitch cables meeting MIL SPEC standards
Durable JST RARSFP-3V-00 RA connector designed for 1.27 mm pitch cables meeting MIL SPEC standards
Specifications
Description :
Housings, Boots RoHS
Mfr. Part # :
RARSFP-3V-00
Model Number :
RARSFP-3V-00
Description

RA CONNECTOR

The RA connector series offers highly reliable and cost-efficient IDC (Insulation Displacement Connector) solutions for 2.54 mm and 1.27 mm pitch ribbon cables. Designed to meet MIL-SPEC (MIL-C-83503) compliance, these connectors are interchangeable with commercially available connectors of similar types. They are engineered to address the increasing density of internal and external connection systems in electronics while minimizing labor requirements and overall costs. The RA connectors are based on advanced crimping connection technology, utilizing carefully selected materials, shapes, dimensions, and surface treatments for optimal performance.

Product Attributes

  • Brand: JST
  • Certifications: MIL-SPEC (MIL-C-83503) compliant, RoHS2 compliance
  • Material: Copper alloy (contacts), PBT(GF) (housing, cover, strain relief)
  • Color: Black (housing, cover, strain relief)

Technical Specifications

TypeNo. of circuitsPitchContact MaterialSurface FinishCurrent RatingVoltage RatingTemperature RangeApplicable WireContact Resistance (Initial)Withstanding VoltageInsulation Resistance
Receptacle10-601.27 mmCopper alloySelective gold-plated / Tin-plated1.0 A AC/DC300 V AC/DC-55 to +125 (Tin-plated: -55 to +105)AWG #28, 1.27 mm pitch ribbon cable10 m max. (Tin-plated: 40 m max.)500 VAC for 5 seconds5,000 M min.
Header10-601.27 mmCopper alloySelective gold-plated / Tin-plated1.0 A AC/DC300 V AC/DC-55 to +125 (Tin-plated: -55 to +105)AWG #28 solid wire / AWG #28 stranded wire10 m max. (Tin-plated: 40 m max.)500 VAC for 5 seconds5,000 M min.

2504101957_JST-RARSFP-3V-00_C566597.pdf
