power connection Anderson Power PSBS50BLK connector rated for 110 amps in demanding electrical setups
power connection Anderson Power PSBS50BLK connector rated for 110 amps in demanding electrical setups
power connection Anderson Power PSBS50BLK connector rated for 110 amps in demanding electrical setups
power connection Anderson Power PSBS50BLK connector rated for 110 amps in demanding electrical setups
Specifications
Description :
Blade Type Power Connector Housings RoHS
Mfr. Part # :
PSBS50BLK
Model Number :
PSBS50BLK
Description

Product Overview

The SBS connector family, including the SBS 50, SBS 75X, and SBS 75G models, offers high-power connectivity in compact, ergonomic housings with protection against accidental contact with live circuits. Designed for applications where DC voltages exceed 30 volts, these connectors provide power contacts rated up to 110 amps. Configurations include wire-to-wire and wire-to-board options. The SBS 75X features up to 4 mate-last, break-first auxiliary power/signal contacts rated up to 20 amps, while the SBS 75G includes a third first-mate, last-break ground or power contact. All contact positions are rated for circuit interruption (hot plugging), ensuring safety and reliability in demanding environments.

Product Attributes

  • Brand: Anderson Power Products (APP)
  • Series: SBS 50, SBS 75X, SBS 75G
  • Housing Material: Polycarbonate (Standard), PBT/PC Blend (Chemical Resistant)
  • Contact Material: Silver Plated Copper Alloy (Power/Ground), Gold Plated Copper Alloy (Auxiliary Pins), BeCu/Gold Plated Copper Alloy (Auxiliary Sockets)
  • Flammability Rating: UL94 V-0
  • Glow Wire Rating: SBS50: 825C (GWFI) / 800C (GWIT); SBS75G/X: 960C (GWFI) / 800C (GWIT)
  • Certifications: IEC 60950, IEC 60664-1, UL 1977, CSA/TUV
  • Gender: Genderless Design
  • Keying: Mechanical keys are color coded

Technical Specifications

Specification SBS 50 SBS 75X SBS 75G
Primary Power Current Rating (UL) 110 Amps (6 AWG) 110 Amps (6 AWG) 110 Amps
Auxiliary Power/Signal Current Rating N/A Up to 20 Amps Up to 20 Amps (Ground/Power)
Voltage Rating (AC/DC) 600V 600V 600V
Dielectric Withstanding Voltage (AC) 2,200 Volts 2,200 Volts 2,200 Volts
Mating Cycles (Power/Ground) 10,000 10,000 10,000
Mating Cycles (Auxiliary) N/A 10,000 10,000
Operating Temperature (Standard) -20C to 105C (-4F to 221F) -20C to 105C (-4F to 221F) -20C to 105C (-4F to 221F)
Operating Temperature (Chemical Resistant) -40C to 105C (-40F to 221F) -40C to 105C (-40F to 221F) N/A (Inquire for CR housings)
Wire Size Range (Power) 16 to 6 AWG (1.3 to 13.3 mm) 16 to 6 AWG (1.3 to 13.3 mm) 16 to 6 AWG (1.3 to 13.3 mm)
Wire Size Range (Auxiliary) N/A 24 to 12 AWG (0.25 to 3.3 mm) 24 to 12 AWG (0.25 to 3.3 mm)
Configurations Wire-to-Wire, Wire-to-Board Wire-to-Wire, Wire-to-Board (with PCB Connector) Wire-to-Wire, Wire-to-Board (with PCB Connector)
Touch Safe Interface Yes (IEC 60950) Yes (IEC 60950) Yes (IEC 60950)
Circuit Interruption Yes (Hot Plugging) Yes (Hot Plugging) Yes (Hot Plugging)
