Male formed contact EATON SM24M1S31 constructed from copper alloy with stainless steel outer spring
Male formed contact EATON SM24M1S31 constructed from copper alloy with stainless steel outer spring
Specifications
Description :
Multi Purpose RoHS
Mfr. Part # :
SM24M1S31
Model Number :
SM24M1S31
Description

Product Overview

This document details SOURIAU's MALE FORMED TWO PIECE CONTACT, designed for use within the TRIM TRIO interconnection system. These contacts are suitable for various connector types including MSM, MSG, MB Rectangular, SMS Qikmate, and UT0, UTS, UTL, UTG, UTP, MBG Circular connectors. They offer reliable performance with a current rating of 13A and are constructed from high conductivity copper alloy with a stainless steel outer spring.

Product Attributes

  • Brand: SOURIAU
  • Origin: FR (EAR99)
  • Material: High Conductivity Copper Alloy (Contact Body), Stainless Steel (Outer Spring)
  • Plating Options: S6 (0.75 Gold Min. OVER Ni), D70 (0.13 Gold Min. OVER Ni), TK6 (0.5-2.5 Sn Pre-plated), S18 (0.75 Gold Min OVER Ni, 1.3 Mini Sn OVER Ni), S31 (Gold Flash OVER Ni, 1.3 Mini Sn OVER Ni), D70REV (0.13 Gold Min. OVER Ni, 1.3 Mini Sn OVER Ni)
  • Certifications: FR (EAR99)

Technical Specifications

CAT. NPackageWIRE SIZE (AWG)WIRE SIZE (MM)WIRE INSUL. DIAM. (MM)WIRE STRIP LENGTH (MM)HAND CRIMP TOOLINGEXTRACTION TOOL
SM24M1L*Loose contacts in plastic bag26/240.12/0.250.90/1.604.0S16SCM20RX2025GE1
SM24M1* / SM24M1*REVStrip contacts on reel26/240.12/0.250.90/1.604.0S16SCM20RX2025GE1
SM20M1L*Loose contacts in plastic bag22/200.32/0.501.20/2.104.0S16SCM20SHANDLES
SM20M1* / SM20M1*REVStrip contacts on reel22/200.32/0.501.20/2.104.0S16SCM20SHANDLES
SM16M11L*Loose contacts in plastic bag18/160.82/1.503.0 Max 4.653.0S16SCML11SHANDLES
SM16M11* / SM16M11*REVStrip contacts on reel18/160.82/1.503.0 Max 4.653.0S16SCML11SHANDLES
SM16M1L*Loose contacts in plastic bag18/160.82/1.503.2 Max 6.353.2S16SCML1SHANDLES
SM16M1* / SM16M1*REVStrip contacts on reel18/160.82/1.503.2 Max 6.353.2S16SCML1SHANDLES
SM14M1L*Loose contacts in plastic bag142.10/2.503.2 Max 6.353.2S16SCML1SHANDLES
SM14M1* / SM14M1*REVStrip contacts on reel142.10/2.503.2 Max 6.353.2S16SCML1SHANDLES
Performance CharacteristicValue
Current Rating13 A
Contact Retention in Body65 N MIN.
Contact Resistance<= 6m Ohm
Individual Insertion Force3.5 N MAX.
Operating Voltage750 V RMS
Individual Withdrawal Force0.55 N MIN.
