Industrial Ethernet Connector Bel Fuse S-RJFTV5E17021N with 500 Mating Cycles and IP68 Protection
Industrial Ethernet Connector Bel Fuse S-RJFTV5E17021N with 500 Mating Cycles and IP68 Protection
Specifications
Connector Type :
-
Shielding :
有屏蔽
Description :
Shielded Modular/Ethernet Connector Jacks RoHS
Mfr. Part # :
S-RJFTV5E17021N
Model Number :
S-RJFTV5E17021N
Description

Product Overview

Stewart Connector's RJ45 D38999 Series S-RJFTV offers robust Ethernet connectivity for harsh environments, leveraging the D38999 shell and high-performance RJ45 connectors. Its unique, compact design, available in the market's smallest size 17, supports 1G Base-T Ethernet transmission. This series is ideal for demanding applications in military communication, railway, oil and gas, and renewable energy industries, providing reliable data transmission for 10 Base-T, 100 Base-T, and 1G Base-T Ethernet up to 100 MHz.

Product Attributes

  • Brand: Stewart Connector
  • Series: RJ45 D38999 Series S-RJFTV
  • Shell Style: D38999 series III
  • EMI Protection: Shielded cable
  • Mating Cycles: Minimum of 500
  • Sealing: IP68
  • Keyways: Four available
  • Performance: Up to 100 MHz

Technical Specifications

Specification Details
Ethernet Speeds 10 Base-T, 100 Base-T, 1G Base-T
Shell Sizes 17, 19
Panel Thickness (Max) .125 [3.2]
Panel Mounting Diameter (Front) 1.016 [25.81]
Panel Mounting Diameter (Rear, if back shell used) 1.219 [30.96]
How to Order - Performance 5E - Suited for 10 BaseT, 100 BaseT, 1G BaseT
How to Order - Shell Size 17 - Size 17, 19 - Size 19
How to Order - Shell Type 02 - Receptacle, square flange
02BS - Receptacle, square flange, IP68 backshell, plastic gland
02BSM - Receptacle, square flange, IP68 backshell, metal gland
06P - Plug, straight, plastic gland
06M - Plug, straight, metal gland
07 - Receptacle, jamnut
07BS - Receptacle, jamnut, IP68 backshell, plastic gland
07BSM - Receptacle, jamnut, IP68 backshell, metal gland
How to Order - Back end termination 1 - RJ45, Female, Straight (omit for shell type 06)
How to Order - Shell Material and Plating G - Aluminum shell, olive drab plating
N - Aluminum shell, nickel plating (RoHS)
SS - Stainless steel, passivated (RoHS)
BZ - Marine bronze (RoHS)
How to Order - Cordset length 03 - 0.3 meter
05 - 0.5 meter
10 - 1.0 meter
15 - 1.5 meter

2411220406_Bel-Fuse-S-RJFTV5E17021N_C6801438.pdf
