compact NGFF memory module socket FOXCONN AS0BC21-S40BB-7H single row horizontal type with 67 contacts
compact NGFF memory module socket FOXCONN AS0BC21-S40BB-7H single row horizontal type with 67 contacts
Specifications
Number of Pins :
67P
Connector Type :
母
Interface Form :
M.2-B Key
Operating Temperature :
-40℃~+80℃
Mounting Type :
卧贴
Description :
67P Surface Mount, Right Angle SMD,P=0.5mm,Surface Mount,Right Angle Centronics Connectors RoHS
Mfr. Part # :
AS0BC21-S40BB-7H
Package :
SMD,P=0.5mm,Surface Mount,Right Angle
Model Number :
AS0BC21-S40BB-7H
Description

Product Overview

The AS0BC2*-S40B*-7H is a single-row horizontal NGFF (Next Generation Form Factor) memory module socket designed for M.2 connectors. It features 67 contacts and 2 metal tabs, offering a compact and reliable solution for memory expansion in various computing applications.

Product Attributes

  • Brand: HON HAI PRECISION IND. CO.,LTD.
  • Origin: TAIPEI, TAIWAN, R.O.C.
  • Material: PI-FILM (POLYIMIDE), COPPER ALLOY, STAINLESS STEEL, THERMOPLASTIC (UL94V-0, HALOGEN FREE)
  • Color: BLACK
  • Certifications: HALOGEN/LEAD FREE

Technical Specifications

Part NumberModule TypeHeight (mm)Width (mm)Length (mm)Contact Current RatingVoltage RatingInsulation ResistanceDielectric Withstanding VoltageContact Resistance (Initial)Contact Resistance (After Test)DurabilityOperation TemperatureSMT Peak TemperatureContact Area Plating
AS0BC2*-S40B*-7HNGFF SINGLE ROW HORIZONTAL TYPE4.0mm67POS.N/A0.5 Ampere MAX. PER PIN50V AC500 MEGAOHMS MIN. AT 500V DC300V AC RMS AT 60Hz, FOR 1 MINUTE55 MILLIOHMS MAX. PER PIN20 MILLIOHMS MAX. PER PIN60 MATING CYCLES-40 C TO +80 C260 C, 10~20SGOLD FLASH / 5u" GOLD / 6u" GOLD / 7u" GOLD / 30u" GOLD

2410121930_FOXCONN-AS0BC21-S40BB-7H_C2761526.pdf
