CUI MP-2511
CUI MP-2511
CUI MP-2511
CUI MP-2511
CUI MP-2511
CUI MP-2511
CUI MP-2511
CUI MP-2511
Specifications
Contact Material :
Brass
Stock :
9270
Voltage Rating (Max) :
12V
Brand Name :
MP-2511
Operating Temperature :
-25℃~+70℃
Delivery Time :
10-15 working days
Description :
-25℃~+70℃ 12V 1A Brass Audio Connectors RoHS
Packaging Details :
-
Current Rating :
1A
Model Number :
MP-2511
MOQ :
1000
Description

Product Overview

The CUI Devices MP-2511 is a 2-conductor audio plug designed for overmolding applications. It offers reliable electrical connections with specified contact and insulation resistance, and is built to withstand standard insertion and withdrawal forces.

Product Attributes

  • Brand: CUI Devices
  • Certifications: RoHS
  • Material (Insulator): POM (UL94HB)
  • Material (Tip): Brass
  • Material (Sleeve): Brass
  • Color (Insulator): Black
  • Plating (Tip): Nickel
  • Plating (Sleeve): Nickel

Technical Specifications

ParameterConditions/DescriptionMinTypMaxUnits
Rated Input Voltage12Vdc
Rated Input Current1A
Contact ResistanceBetween plug and jack50m
Insulation ResistanceAt 100 Vdc100M
Voltage WithstandFor 1 minute500Vac
Insertion ForceWhen mating with a standard jack0.44kgf
Withdrawal ForceWhen mating with a standard jack0.44kgf
Operating Temperature-2570C
Operating Humidity85%
Life5,000cycles
Flammability RatingSee material table
Hand SolderingFor maximum 1 second380400420C
