Keystone 921
Keystone 921
Keystone 921
Keystone 921
Keystone 921
Keystone 921
Specifications
Delivery Time :
6-13工作日
Model Number :
921
Brand Name :
921
Packaging Details :
Through Hole
MOQ :
3
Description :
Through Hole USB, DVI, HDMI Connector Assemblies RoHS
Description

USB 2.0 Plugs & Sockets

This series of USB 2.0 plugs and sockets offers versatile connectivity solutions for a wide range of on-board and custom cable applications. Featuring gold-plated contacts for low resistance and excellent reliability, these components are designed for durability and high performance. Available in various mounting styles including surface mount, horizontal, dual stacking, and thru-hole, they cater to diverse PCB design requirements. Ideal for daisy-chaining multiple input devices, these products are suitable for applications such as memory sticks, MP3 players, digital cameras, mice, keyboards, and PDAs.

Product Attributes

  • Brand: Keyelco (implied by contact information)
  • Certifications: UL Rated 94V-0, ISO 9001 Certified, RoHS Compliant
  • Material (Sockets): Shell - Phosphor Bronze, Insulator - Thermoplastic, Contacts - Phosphor Bronze, Contact Area - Gold Flash over Nickel, Solder Trails - Tin over Nickel
  • Material (Plugs): Shell - Steel (Nickel Plate), Insulator - Thermoplastic, Contact - Bronze (Gold Flash over Nickel)
  • Origin: USA (implied by contact information)

Technical Specifications

Category No. Type Description Rated Voltage Contact Current Rating Contact Resistance Insulation Resistance Dielectric Withstanding Voltage Operating Temperature Durability
920 Socket Surface Mount 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
921 Socket Thru Hole Mount 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
922 Plug Cable Clamp Style 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
923 Plug On-board Applications (e.g., memory sticks) 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
925 Socket Dual Stacking 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
931 Socket Horizontal 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
932 Socket Surface Mount 30V (RMS) 1 Amp DC max. 15 m max. 1000 m min. 750V AC for 1 minute -13F (-25C) to +176F (+80C) 1500 Cycles min.
