TE Connectivity 2382635-1
TE Connectivity 2382635-1
TE Connectivity 2382635-1
TE Connectivity 2382635-1
TE Connectivity 2382635-1
TE Connectivity 2382635-1
Specifications
Packaging Details :
-
Pitch :
15.3mm
Delivery Time :
25-42周
Brand Name :
2382635-1
Operating Temperature :
-40℃~+105℃
MOQ :
1000
Stock :
100000
Model Number :
2382635-1
Description :
15.3mm -40℃~+105℃ Solid State Lighting Connector Assemblies RoHS
Description

Product Overview

The TE Connectivity LUMAWISE Power Input Terminal Block (TB) is an advanced wire termination solution designed as a direct replacement for traditional terminal blocks in LED outdoor lighting luminaires and HID luminaires. It features a unique rising vice clamp screw design for power input and lever-actuated spring cage clamp connections for signal output, simplifying wiring and enhancing operator ergonomics. This terminal block is engineered for robust performance and ease of installation in demanding lighting applications.

Product Attributes

  • Brand: TE Connectivity
  • Product Line: LUMAWISE
  • Origin: Not specified
  • Material: Housing, lever, and cover: PBT; Spring contact: Stainless steel; Contacts: Copper alloy, tin plated; Screw: Steel, zinc plated
  • Color: Not specified
  • Certifications: UL 1059: Terminal Block; ANSI C136.14 compliant

Technical Specifications

FeatureSpecification
Power Input ConnectionsRising vice clamp screw; Terminal captive screw; Accepts 6 - 14 AWG solid and stranded copper wires; 3 positions
Signal Output ConnectionsLever actuated spring clamp poke-in; Accepts up to three 12 - 18 AWG solid or stranded copper wires per input position; Multi-wire lever remains in open position hands-free; Lever actuation required to secure connections
Electrical Rating15A, 480VAC
Mechanical Rating-40 to 105C environmental rating
Mounting2-sided mounting hole slots for drop-in replacement
Application AreasRoadway, street, and area lighting luminaires; Commercial lighting (e.g., parking lots, car dealerships); Decorative lighting luminaires; Wall pack and wall wash lighting fixtures
Part Number2382635-1
Part DescriptionLUMAWISE Power Input Block
