LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Specifications
Brand Name :
Cablein
Certification :
CE, ROHS, TUV , ETL
Place of Origin :
Shenzhen China
MOQ :
100PCS
Price :
The price ranges from $1 to $4 USD per pieces
Payment Terms :
T/T,Western Union
Delivery Time :
5-8 Working Days
Packaging Details :
High Quality export carton
Name :
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Waterproof :
IP68/IP67
Flame Resistanc :
UL94 V-0
Metal :
Gilded brass
Material :
Metal + Plastic
Insertion life :
≥1900 times
Dustproof :
100% Dustproof
Withstand Temperature :
-40℃~+80℃
Description
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Specifications
  • Pin: 7 Pin
  • Current Rating(A): 10A Max
  • Material: Metal+plastic
  • Conenction Way: Push-button snap fastener
  • Operating Voltage: 500V Max
  • Assembly Wire: IP-Rated Locking Gland
  • Mounting Type: Flange Mounting Type
  • Out Door UV Resistance: Pass
  • Cable Jacket OD: 1-1.5 mm²
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type datasheet
Pins Number 2Pins 3Pins 4Pins 5Pins 7Pins 9Pins 12Pins
Rated Voltage 500V
250V
Rated Current 20A 10A 5A
Insulation voltage 2.5KV 1.5KV
IP CODE IP68
Cable Jacket OD Standard Power:⌀8-12mm Standard Signal :⌀5-6.5mm Other:⌀5-9mm
Assembly cable diameter 2.4-4mm²/14-12AWG 1-1.5mm²/18-16AWG 0.34-0.75mm²/22-20AWG
Ambient temperature -40℃~+80℃
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type Advantages:
  1. Material & Performance:
    The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments.
  2. Secure Locking Mechanism:
    Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal.
  3. Waterproof Design:
    Standard IP67 rating (IP68 optional) provides precise waterproof protection.
  4. Certifications & Compliance:
    Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.
  5. High Current Capacity: Supports 20A power transmission, making it suitable for medium-to-high-power applications
  6. Versatile Compatibility: The 4-core design allows for multiple signal/power transmissions in a single compact connector.
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type Application industries
Automation Equipment
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LED Lighting
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Security Equipment
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Telecommunication Equipment
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
New Energy
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
Electronic Devies
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type
LP20 7-Pin Waterproof Signal Connector 10A IP67 Metal-Plastic Flange Locking Type Drawing
