M25 Waterproof Aviation Connector Push Pull 300V Multi Pin 2+20 Pin Connector
Signal and Power Multi Connector Solution
Designed for synchronous transmission of power and multi-channel data in industrial equipment, the M25 2+20 Pin Waterproof Multi-Connector (300V Wire-to-Board Type) features an integrated design that solves complex connection problems in industrial scenarios. With functional partitioning of 2-pin power supply and 20-pin data transmission, combined with M25 high-sealing interface technology, this connector is ideal for outdoor intelligent sorting, large-scale environmental monitoring, industrial robot end effectors, new energy BMS, and other equipment applications.
Advanced Design Features
The M25 circular structure incorporates independent insulating chambers that physically separate the 2-pin power channel from the 20-pin data channel. Rated for 300V operation to meet industrial power requirements, the design eliminates signal interference. The quick-lock docking mechanism requires no tools and achieves automatic locking with one-second insertion for maximum efficiency. This ensures stable power output and accurate multi-channel data collection in harsh outdoor conditions including humidity, dust, and vibration.
Application Industries
  • Communications Applications
  • Product Coding Machines
  • Inventory Product Coding
  • Inkjet Systems
  • Solar Systems
  • Industrial Inkjet Equipment
  • Electric Power Equipment
  • Laboratory Forensic & Pathology Equipment
  • Communications Equipment
  • Heavy Machinery
Main Features
  • Field assembly version cable to board
  • Cable assembly service available
  • Quick lock fast release structure
  • Waterproof rated for most outdoor applications
  • Power and signal in one integrated set
  • 2-pin power + 20-pin signal arrangement
Electrical Parameters
Number of Poles 22-pin wire to board connector
Current Rating 20A + 5A
Voltage Rating 300VAC max
Durability Voltage 2500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 600VAC max
Current Rating 40A max
Min Wire Size OD 6.5mm ~ 10mm
Max Wire Size OD 10.5mm ~ 18mm
Max Cable Cross Section Area 0.5mm² ~ 6.0mm²
Product Configuration
M25 Waterproof Aviation Connector Push Pull 300V Multi Pin 2+20 Pin Connector
Product Dimension
M25 Waterproof Aviation Connector Push Pull 300V Multi Pin 2+20 Pin Connector
More Technical Details
M25 Waterproof Aviation Connector Push Pull 300V Multi Pin 2+20 Pin Connector
