2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
Specifications
Brand Name :
Ulinkcon
Model Number :
M25
Certification :
CE/Rohs/TUV/UL
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/A,D/P,MoneyGram,L/C
Supply Ability :
100000 pairs each month
Delivery Time :
5~8 working days
Packaging Details :
Box
Number of Pins :
2+20Pin waterproof connector
Contact Material :
Brass Gold-Plated
Temperature Range :
-40℃~+105℃
Waterproof Rating :
IP67
Application :
Solar Panel
Color :
Red/Blue/Green
Flame-resistant rating :
UL94-V0
Description
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
2+20 Pin Quick Release IP67 Wire To Board Power And Signal Connectors. M25 Power Signal Connector 2+20 Pin IP67 20A+5A Wire To Board Connector.
Product Overview
Signal And Power Multi Connectors M25 2+20 Pin Waterproof 300 Volt Wire To Board
Key Features
  • High Waterproof Performance: IP67 protection grade prevents dust, rainwater, and pollutants from entering. Withstands short-term immersion (≤1m depth, ≤30 minutes) without affecting signal transmission.
  • Standard M25 Interface Design: Push-lock interface with excellent sealing and firm installation. Compatible with standard M25 mounting accessories for easy assembly and maintenance.
  • 2+20 Pin Configuration: 22 pins total (2 power + 20 signal) for separate power supply and signal transmission. Supports multi-channel cable-to-board connections.
  • Cable to Board Connection: Specialized C2B connection with precise pin positioning and tight contact for low resistance and stable signal transmission.
  • Outdoor & Panel-Mounted Application: Resistant to high/low temperatures, UV radiation, and aging. Designed for seamless panel integration in harsh outdoor environments.
  • Stable Signal Transmission: High-quality conductive materials with excellent conductivity and corrosion resistance for minimal signal loss and interference.
Application Industries
Communications Equipment Product Coding Machines & Inkjet Systems Solar Systems Electric Power Equipment Laboratory Forensic & Pathology Equipment Heavy Machinery Industrial Inkjet Equipment
Technical Specifications
Electrical Parameters
Number of Poles 22 pin wire to board connector
Current Rating 20A + 5A
Voltage Rating 300VAC max
Durability Voltage 2500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Operation Parameters
Voltage Rating 600VAC max
Current Rating 40A max
Min Wire Size OD 6.5mm ~ 10mm
Max Wire Size OD 10.5mm ~ 18mm
Max Cable Cross Section Area 0.5mm² ~ 6.0mm²
Product Configuration
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
Product Dimension
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
Technical Details
2+20 Pin Waterproof Connector M25 Outdoor IP67 Cable Connectors Signal Panel
Frequently Asked Questions
What is rated voltage?
Rated voltage, also known as operating voltage, depends on the connector insulation material used and the spacing between contact sizes. Some components or devices may not function properly below their rated voltage.
Is there a discount for large-quantity orders?
Yes, we offer tiered discounts for bulk orders. The more you order, the more competitive the price. Please inform us of your expected quantity for a customized quotation.
How to track my shipment?
Once goods are shipped, we provide tracking numbers and logistics platform links. You can track real-time status online or contact our team for updates.
