300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
Specifications
Brand Name :
Ulinkcon
Model Number :
M19
Certification :
CE/Rohs/TUV/UL
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/P,L/C,D/A,,Western Union,MoneyGram
Supply Ability :
100000 pairs Montly
Delivery Time :
3~6working days
Packaging Details :
1.Plastic bag;2.Carton;3.As per customer's requirements
Pin :
10Pin
Material :
Nylon
Current rating :
5A
Rated voltage :
300V
Gender :
Male to Female
Type :
Plug/Socket
Description
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
Product Overview

M19 10 Pin Waterproof Quick Disconnect Wire To Board Connectors

Quick Description
  • Core Specifications & Panel-Mounted Design: M19 series 10-pin waterproof panel connector, rated voltage 300V, made of high-quality PA66 plastic material, adopts push-pull connection mode, specialized for data transmission scenarios.
  • IP67 Waterproof & Dustproof Protection: Integrated high-sealing structure with wear-resistant silicone sealing ring, fully compliant with IP67 protection grade.
  • PA66 Material Advantages: The shell is made of industrial-grade PA66 plastic, which has excellent properties such as high strength, impact resistance, anti-aging, anti-UV and corrosion resistance.
  • Push-Pull Connection & Operation Convenience: Adopts precision push-pull connection structure, which is smooth to operate—push to connect and pull to disconnect, fast and firm.
  • 10-Pin Data Transmission Performance: 10-pin independent design, reasonable pin layout, low contact resistance (≤10mΩ), excellent signal anti-interference performance.
  • Applicable Scenarios: Widely used in industrial control equipment, instrumentation, communication equipment, outdoor electronic devices, medical equipment, and smart equipment.
Electrical Parameters
Number of Poles 10Pin
Current Rating 5A max.
Voltage Rating 300VAC max
Durability Voltage 1500VAC @ 60 s.
Application Industries
  • Growth Lights
  • Communications Application
  • Product coding machines
  • Inventory product coding
  • Inkjet systems
  • Solar System
  • Industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic & pathology equipment
  • Communications equipment
  • Heavy machinery
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min) when mated
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Main Features
  • Push lock quick release system
  • Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin for Power
  • 3+2Pin, 3+3Pin, 3+4Pin, 3+5Pin, 3+9Pin and 2+20Pin for power signal combined
  • 6Pin, 7Pin, 8Pin, 9Pin, 10Pin, 11Pin, 12Pin, 14Pin, 16Pin and 18Pin for signal available
  • Field assembly version: both wire to wire and wire to board options
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome
Operation Parameters
Voltage Rating 300VAC max
Current Rating 5A max
Min Wire Size OD 3.0mm ~ 6.0mm
Max Wire Size OD 8.0mm ~ 10.0mm
Max. Cable Cross Section Area 0.5mm² ~ 2.5mm²
Design Sketch
300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors 300V M19 10 Pin Waterproof Panel Connector Plastic PA66 Push Pull Data Connectors
Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q: How can I get samples?
A: It's my honor to offer you samples, and the freight should be paid by yourself. You can let me know your courier number and your detail address, then I can send you sample at once.
Q: How to track my shipment?
A: Once the goods are shipped, we will send you the tracking number and logistics platform link. You can track the real-time status online or contact our team for updates.
