M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
Specifications
Brand Name :
Ulinkcon
Model Number :
M25
Certification :
CE/Rohs
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T,D/A,D/P,MoneyGram,L/C
Supply Ability :
100000 pairs each month
Delivery Time :
5~8 working days
Packaging Details :
Box
Number of Pins :
3+13PIN
Current :
15A+5A
Waterproof Rating :
IP67
Temperature Range :
-40℃~+105℃
Flame-resistant rating :
UL94-V0
Contact Material :
Brass Gold-Plated
Description

3+13 Pin Plug Socket Waterproof M25 Data And Power Connector IP67,Quick Locking


Main Features

  • Push lock quick release system
  • Multic-core options: 2Pin,3Pin,4Pin,5Pin,3+2Pin,3+3Pin,3+9Pin,3+13Pin and 2+20Pin
  • Field assembly version:both wire to wire and wire to board options
  • Current rated 20A for long time working
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome


Quick Details of 16Pin Connector Male female

1. Key Specifications

  • Core Craftsmanship: Gold-plated terminal design enhances electrical conductivity and anti-oxidation performance, prolonging the product's service life
  • Interface Details: M25 dimension with 3+9 Pin multi-pin configuration, enabling Male-Female mating and compatible with Panel Mount applications
  • Electrical Ratings: 30A rated current and 300V rated voltage, ideally suited for power supply and signal transmission requirements of medium-power devices
  • Protective Performance: Waterproof construction ensures reliable operation in harsh outdoor environments, effectively resisting humidity and dust


2. Core Product Advantages

  • Gold-Plated Terminal Benefits: Minimal contact resistance ensures efficient and stable electrical transmission, with outstanding anti-oxidation and corrosion resistance
  • Easy Installation & Docking: Supports Panel Mount, featuring Male-Female mating structure for precise positioning and hassle-free assembly/disassembly
  • Integrated Multi-Pin Function: 3+9 Pin independent circuits enable simultaneous power supply and multi-channel signal transmission, achieving high functional integration
  • Outdoor Durability: Sealed waterproof design effectively withstands rain, moisture and dust, making it suitable for long-term outdoor service


3. Application Scenarios

  • Widely used in outdoor monitoring equipment, outdoor lighting systems and other scenarios requiring outdoor waterproof power supply
  • Suitable for industrial automation production lines, outdoor testing instruments and other equipment that need to transmit power and multi-channel signals at the same time
  • Applicable to various medium-power outdoor electrical equipment connection needs requiring Panel Mount and Male Female docking

4. Custom Services
  • Provides customization services for M25 3+9 Pin multi-pin connectors, which can be adapted according to actual installation dimensions and cable specifications (wire diameter/length)
  • For customization, detailed usage scenarios and technical parameters need to be provided, and a professional team will provide exclusive Panel Mount adaptation

Application industries


  • Communications Application
  • product coding machines
  • inventory product coding
  • inkjet systems
  • Solar System
  • industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic&pathology equipment
  • Communications equipment
  • Heavy machinery


Product Type Features
Connector System  Cable-to-Board
Sealable  Yes
Connector & Contact Terminates To  Wire & Cable
Circular Connector Type  Plug, Receptacle
Shell Type  Plastic Shell
Product Type  Connector Kit
Configuration Features
Number of Positions  3+13
Number of Signal Positions  13
Contacts Preloaded  Yes
Electrical Characteristics
Operating Voltage (VAC) 300V max.
Operating Voltage (VDC) 300V max.
Body Features
Shell Material  PA66
Circular Connector Insulation Material Type  Low Fire Hazard Thermoplastic
Hermetically Sealed   Yes
Entry Style  Side
Environmental Protection Type  Elastomer Sealed, Hermetically Sealed
O-Ring Material  Elastomer Sealed, Hermetically Sealed
Environmental Protection  Yes
Contact Features
Contact Current Rating (Max) (A) . 15A max.
Circular Connector Contact Type  Pin-Socket
Mechanical Attachment
Connector Mounting Type  Cable Mount (Free-Hanging)
Mating Alignment Type  Keyed
Mating Retention  With
Dimensions
Wire Size (AWG) 20AWG,18AWG,16AWG,14AWG,
Usage Conditions
Operating Temperature Range (°C) -40 ~105°C
IP Water Sealing Level  IP67
IP Dust Sealing Level  6
Industry Standards
UL Flammability Rating   UL 94V-0



More Technical Details


M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter

M25 3+13 Pin Panel Mount Connector Signal And Power IP67 Industrial Plug Socket Adapter
