PA66 M25 3+13 Pin Plug And Socket Cable Connector Quick Release
Product Overview

3+13 Pin Plug Socket Waterproof M25 Data And Power Connector IP67 with Quick Locking System

Main Features
  • Push lock quick release system
  • Multic-core options: 2Pin, 3Pin, 4Pin, 5Pin, 3+2Pin, 3+3Pin, 3+9Pin, 3+13Pin and 2+20Pin
  • Field assembly version: both wire to wire and wire to board options
  • Current rated 20A for long time working
  • Cable assembly service supported, welcome to custom
  • OEM/ODM welcome
Product Construction
The M25 16-Pin Male & Female Connector is a high-efficiency connection solution specifically designed for solar photovoltaic systems. Adopting a multi-pin integrated design and quick-release buckle structure, it realizes precise male-female pairing and tool-free easy plugging, greatly improving the installation and maintenance efficiency of photovoltaic modules. The product housing is made of flame-retardant PA66 engineering plastic with UV aging resistance treatment, combined with an IP67 ultimate protection structure, which can withstand a wide temperature range of -40℃~+105℃, strong UV radiation and salt spray corrosion, perfectly suitable for outdoor harsh scenarios such as rooftop photovoltaic, ground-mounted power plants and distributed photovoltaic systems. Equipped with 3+13 parallel transmission channels for signals/power, it supports ≤600V DC voltage and ≤15A per-pin current output. The silver-plated copper alloy contacts ensure low-resistance and low-loss transmission. Combined with reverse connection protection and short-circuit protection safety designs, it provides reliable guarantee for the stable linkage of solar modules, inverters and energy storage batteries. Its service life is synchronized with the life cycle of photovoltaic modules, making it a core connection component for efficient, safe and durable new energy photovoltaic systems.
Application Industries
  • Communications Application
  • Product coding machines
  • Inventory product coding
  • Inkjet systems
  • Solar System
  • Industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic & pathology equipment
  • Communications equipment
  • Heavy machinery
Technical Specifications
Feature Category Specification
Connector System Cable-to-Board
Sealable Yes
Connector & Contact Terminates To Wire & Cable
Circular Connector Type Plug, Receptacle
Shell Type Plastic Shell
Product Type Connector Kit
Number of Positions 3+13
Number of Signal Positions 13
Contacts Preloaded Yes
Operating Voltage (VAC) 600V max.
Operating Voltage (VDC) 600V max.
Shell Material PA66
Circular Connector Insulation Material Type Low Fire Hazard Thermoplastic
Hermetically Sealed Yes
Entry Style Side
Environmental Protection Type Elastomer Sealed, Hermetically Sealed
O-Ring Material Elastomer Sealed, Hermetically Sealed
Environmental Protection Yes
Contact Current Rating (Max) 15A max.
Circular Connector Contact Type Pin-Socket
Connector Mounting Type Cable Mount (Free-Hanging)
Mating Alignment Type Keyed
Mating Retention With
Wire Size (AWG) 20AWG, 18AWG, 16AWG, 14AWG
Operating Temperature Range -40°C to 105°C
IP Water Sealing Level IP67
IP Dust Sealing Level 6
UL Flammability Rating UL 94V-0
