Specifications
Brand Name :
KRONZ
Model Number :
F1203MA-PF/M12C
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
50 pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
Polybag packing
Description :
M12 Angled Connector
Type :
PCB
Rated Power :
4A/250V
Pin :
2/3/4/5/6/7/8/12
Code :
A/B/D
Rated Impulse Voltage :
2500V
Contact Resistance :
≤ 5
Description
M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male Angled
M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male ​Angled M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male ​Angled M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male ​Angled
Product Specifications
Attribute Value
Description M12 Angled Connector
Type PCB
Rated Power 4A/250V
Pin 2/3/4/5/6/7/8/12
Code A/B/D
Rated Impulse Voltage 2500V
Contact Resistance ≤ 5
Technical Data
Standard IEC 61076-2-101
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material PBT/PA, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -40~+80℃
Mating cycles ≥500
Degree of protection IP67
M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male ​Angled M12 Connector 2 3 4 5 6 7 8 12 Pin A B D Code Screw Locking Plug Male ​Angled
