12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
Specifications
Brand Name :
KRONZ
Model Number :
PRP100-12A40
Place of Origin :
Guangdong, China
Certification :
CE
MOQ :
1
Price :
Negotiable
Packaging Details :
Box Packing
Delivery Time :
5-8 working days
Payment Terms :
T/T, Western Union,
Supply Ability :
10000 pieces per month
Maximum capacitive load (μF) :
10000
Input frequency :
47~63Hz
Weight :
235g
Efficiency (230VAC, %/ Typ.) :
88
Ripple (20MHz ) :
Max. 120mV
Load regulation :
±1.5% (230VAC)
Adjustable output voltage range(ADJ) :
12.0-13.8
Output Voltage&Current :
12V/7.5A
Description
12V 90W Din Rail Mount Industrial Power Supply with Black Plastic Housing Max.120mV
Product Overview
This industrial-grade power supply delivers reliable 90W output with precise voltage regulation, designed for demanding industrial applications. Its compact DIN rail mounting design and black plastic housing make it ideal for integration into control panels and industrial equipment.
Key Specifications
Attribute Value
Output Voltage & Current 12V/7.5A
Output Power 90W
Adjustable Output Voltage Range (ADJ) 12.0-13.8V
Efficiency (230VAC, %/Typ.) 88%
Maximum Capacitive Load 10000μF
Ripple (20MHz) Max. 120mV
Load Regulation ±1.5% (230VAC)
Weight 235g
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV 12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
Technical Specifications
Input Characteristics
AC Input Voltage 85~264VAC
DC Input Voltage 120~370VDC
Input Current 3.0A (115VAC); 1.6A (230VAC)
Input Frequency 47~63Hz
Output Characteristics
Output Voltage Accuracy ±2%
Power-down Hold Time 30ms (230VAC)
Environmental & Safety
Operating Temperature -40~+70°C
Safety Standards UL/IEC62368-1, IS13252(Par1) & EN62368-1, EN61558-1/-2-16, BS EN 62368-1
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV 12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
Applications
This industrial power supply is suitable for:
  • Industrial automation systems
  • Control panels and PLC systems
  • Telecommunications equipment
  • Test and measurement instruments
  • Security and surveillance systems
Product Features
  • High efficiency (88% typical at 230VAC)
  • Wide input voltage range (85~264VAC)
  • Precise voltage regulation (±1.5% load regulation)
  • Compact DIN rail mounting design
  • Robust black plastic housing
  • Compliant with international safety standards
  • Wide operating temperature range (-40~+70°C)
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV 12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
Packaging & Shipping
Each unit is securely packaged in protective foam within a sturdy cardboard box to ensure safe delivery. Shipping typically takes 5-8 working days with tracking information provided.
12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV 12V 90W Din Rail Mout Industrial Power Supply with Black Plastic Housing Max.120mV
