Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Specifications
Brand Name :
KRONZ
Model Number :
PRP30-05A40
Place of Origin :
Guangdong, China
Certification :
CE
MOQ :
1
Price :
Negotiable
Packaging Details :
Box Packing
Delivery Time :
5-8 working days
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
10000 pieces per month
Ripple (20MHz ) :
Max. 80mV
DC Input voltage :
120~370VAC
Maximum capacitive load (μF) :
12000
Adjustable output voltage range(ADJ) :
4.9-5.5
Load regulation :
±1.5% (230VAC)
Weight :
115g
Output Voltage&Current :
5V/3A
Power-down hold time :
12ms (115VAC) ; 60ms (230VAC)
Description
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Key Specifications
Attribute Value
Ripple (20MHz) Max. 80mV
DC Input voltage 120~370VAC
Maximum capacitive load (μF) 12000
Adjustable output voltage range (ADJ) 4.9-5.5
Load regulation ±1.5% (230VAC)
Weight 115g
Output Voltage & Current 5V/3A
Power-down hold time 12ms (115VAC); 60ms (230VAC)
Product Overview
This high-quality industrial power supply delivers reliable AC/DC conversion for demanding industrial applications. With a wide input voltage range of 120-370VAC and maximum capacitive load of 12000μF, it provides stable power for multiple devices simultaneously.
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Technical Specifications
Parameter Value
Model number PRP30-05A40
Output power 15W
Nominal output voltage & current 5V/3A
Efficiency (230VAC) 82% (Typ.)
Input Characteristics
AC Input voltage 85~264VAC
DC Input voltage 120~370VDC
Input current 0.9A (115VAC); 0.5A (230VAC)
Input frequency 47~63Hz
Output Characteristics
Output voltage accuracy ±2%
Ripple (20MHz) Max. 80mV
General Features
Operating temperature -40~+70°C
Safety standards UL/IEC62368-1, IS13252(Par1) & EN62368-1, EN61558-1/-2-16, BS EN 62368-1
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Applications
This versatile power supply is ideal for industrial control systems, sensors, and equipment requiring stable 5V power. Its low ripple (max. 80mV) makes it suitable for sensitive electronics, while the robust design ensures reliable operation in harsh environments (-40 to +70°C).
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
Support & Services
Comprehensive technical support is available for installation, troubleshooting, and maintenance to ensure optimal performance of your power supply system.
Packaging & Shipping
Each unit is securely packaged in a protective cardboard box with bubble wrap and foam inserts. Orders ship within 1-2 business days with tracking provided.
Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance Industrial Power Supply 5V/3A Max.80mV Ripple for 20MHz AC/DC 15W Stable Performance
