M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
Specifications
Brand Name :
KRONZ
Model Number :
F1205F-SR/M16
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
50 pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
Polybag packing
Type :
M12 connector
Decription :
Male flange connectors
Voltage :
250V
Contacts :
Solder cup
Insulation resistance :
≥100MΩ
Contact resistance :
≤5mΩ
Ambient temperature :
-25~+85℃
Mating cycles :
>100
Description
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
Product Specifications
Type M12 connector
Description Male flange connectors
Voltage 250V
Contacts Solder cup
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Ambient temperature -25~+85℃
Mating cycles >100
Product Overview

The M12 Panel Mount Connector Female 5 Pin with rear mounting (M16 x 1.5) offers IP67 protection for reliable performance in demanding industrial environments.

  • 5-pin design ensures accurate and stable signal transmission
  • IP67 protection against dust and moisture intrusion
  • Suitable for pollution level 3 environments
  • Compliant with IEC 61076-2-101 standard
  • Ideal for complex electrical systems in harsh conditions
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67
Technical Specifications
Standard IEC 61076-2-101
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material Brass, nickel-plated
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP67
Configuration Details
Pin assignment Mounting type Coding Rated current Voltage Cable outlet Contacts termination Part No.
M12 Panel Mount Connector Female 5 Pin Rear Mounting M16 X 1.5 IP67 Rear mounting A 4A 60V Straight Solder cup F1205F-SR/M16

For additional requirements or custom specifications, please contact our sales team.
